biomass wood briquette machine

Specifications

wood briquette machine
main motor power 11kw
heating power 5kw
capaicty 400-600kg/h
25 years experence

              Biomass wood briquette machine/extruder wood briquette machine

           25 years manufacturing experience &supply customers Excellent after sell service

Biomass Wood Briquette Materials
Waste wood, old forest, wood leaves, wood chips, old wood and any kinds of wood wastes & agro-waste

Application raw material size below 5mm. (sawdust from sawmill its available)

Application raw material initial moisture its 8-14%

100% all nature ,there are nothing other chemical additive glue mixing .

Biomass Wood Briquette Formation Theory

Sawdust Briquette machine uses a large screw to grind, compress and extrude the biomass /fiber raw material into briquettes. The natural lignin content in biomass is liberated with wood fiber under high pressure and temperature The fiber raw material contains a large amount of lignin and fibrin. As the lignin doesn’t have dissolving point but only softening point, when temperature reaches 70 to 110°C, the hot water soluble substance in lignin begins to dissolve and at 200 to 300°C, it begins to soften. At this point, when posed pressure, the lignin can stick together with fibers and cement with adjacent particles. The briquette making technique is to use this features of the plants and through compression to mold.

Biomass wood Briquette condition of formation

The raw material moisture bears great on formation process and quality of carbon. In case of high water ratio, redundant steam produced in heating can not discharge from the central aperture. Hence, the surface of the wood briquette may crack, what’s worse, it may blast fire or fail to produce briquette. In case of low water ratio, molding is out of the question because a small sum of water can facilitate softening and plasticity for the lignin and fibrin. The optimal size for making briquette its below 5mm.The raw material best moisture its 8-14% .

Main Technical of Single Wood Briquette Machine

1,Name Extruder Briquette Machine

2,Model  zx-200

3,Applications Raw Material Saw Dust Below 5mm

4,Applications Material Initial Moisture 8-14%

5,Wood Briquette Capacity 400-600(kg/h)

6,Wood Briquette Diameter  4-33mm

7,Main Motor Power  18.5kw

8,Heating power  5kw

9,Machine Weight  560kg

10,Dimensions  1600*1200*1200mm

11,Power Supply  380V 50HZ 3 phase(The motor power according customers power supply also )

Advantages of biomass briquettes:
♦ Easy to transport and store as densified product
♦ Better solution to the problem of residue disposal
♦Uniform in size and quality as a kind of biofuel briquette
♦ Reduce excess deforestation by providing a substitute for fuel wood

♦After wood briquette carbonization could get charcoal for BBQ
