2017 Hot Sell Pellet Making Machinery in EU

2017 Hot Sell Pellet Making Machinery in EU photo-1
2017 Hot Sell Pellet Making Machinery in EU photo-2
2017 Hot Sell Pellet Making Machinery in EU photo-3
2017 Hot Sell Pellet Making Machinery in EU photo-4
2017 Hot Sell Pellet Making Machinery in EU photo-5
2017 Hot Sell Pellet Making Machinery in EU photo-6
US$ 400 - 4,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
chengda machine
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name chengda machine
Model Number KL400C
Voltage 380V
Power(W) 30kw
Dimension(L*W*H) 145*62*115cm
Weight 660kg
Certification CE ISO
Warranty 1 Year
After-sales Service Provided No overseas service provided
Product Description
Flat Die Pellet Machines
Our flat die pellet machines are devided into the KL series pellet machines and the MKL series pellet machines.  Our KL series pellet machins can both press the feed pellets and the wood sawdust pellets, but the capacity of making wood sawdust pellets is lower than that of feed pellets. Our MKL series pellet machines have the  special design for making wood sawdust pellets.
Our flat die pellet machines can be powered by electrical motor, diesel enginen, gasoline engine and tractor. KL-A series pellet machines are driven by the diesel engine or gasoline. KL-B and KL-C series pellet machines are driven by the electrical motor and the KL-P pellet machines are driven by tractor.

KL Series Feed Pellet Machine--- KL400C


1.This machine is flat die pellet machine driven by 30 kw electrical motor.
2. It can not only press feed pellets, but also press wood sawdust pellets.
3. The size of the final pellets: 2.5-10mm is ok, if you make animal feed pellets, 2.5-4mm is better. If you make the wood pellets, 6-8mm is better.
4. Moisture content of the raw materials: 12%-20%.
5. Feed Capacity: 800-1500kg/h
Saw Dust Capacity: 500-600kg/h

The Specific Parameters of KL-C Series Pellet Mills

Model
Power
Die Diameter
Die Hole Specification
Saw Dust Capacity
Feed Capacity
Packing Size (cm)
KL120C
3KW
120mm
2.5-10mm
40-60kg/h
60-100kg/h
80*35*74cm
KL150C
4KW
150mm
2.5-10mm
50-90kg/h
90-120kg/h
80*35*74cm
KL200C
7.5KW
200mm
2.5-10mm
110-140kg/h
200-300kg/h
100*46*95cm
KL230C
11KW
230mm
2.5-10mm
150-190kg/h
300-400kg/h
114*48*105cm
KL260C
15KW
260mm
2.5-10mm
220-280kg/h
400-600kg/h
123*53*107cm
KL300C
22KW
300mm
2.5-10mm
280-320kg/h
600-800kg/h
128*60*105cm
KL360C
22KW
360mm
2.5-10mm
300-380kg/h
700-900kg/h
134*58*106cm
KL400C
30KW
400mm
2.5-10mm
400-550kg/h
900-1200kg/h
152*60*115cm

Advantages of Feed Pellet Machines

1).Simple structure, wide adaptability, covers a small area, low noise. High efficient and low consumption
2).Powder feed, grass meal doesn’t need or with a little liquid, then can be making for granulation.So basic to the moisture content of grain feed granulating before the moisture of the materials, more conducive to storage.
3).Chicken, duck, fish, cattle.pig, birds, dog, etc, than the mixed powder feed can obtain higher economic benefits.
4).Dry processing, the production of feed particle high hardness, smooth surface, internal curing, can improve the digestion and absorption of nutrients.


Widely Applications of Feed Pellet Mills


It is used for pressing materials such as grain, firewood, stalk, tree branches, wood meal, fruit hull, palm and tailing of cotton plant, and widely used for recycle of livestock farms, biomass fuel plant, power plant, wood processing plant, fertilizer plant, chemical plant, food plant and cotton plant.


Kinds of Raw Materials

Pellets as Animal Feed

Raw Materials: soybean meal, corn, straw, green fodder, meat and bone meal, whey powder, fish meal, alfalfa, straw, grass, leaves, etc.

Pellets as Stove Fuel

Raw Materials: straw, alfalfa, wood waste, cornstalks, cardboard, grass, leaves, clippings,rice husks, branches, wood shavings, sawdust,etc.


Certifications
Detailed Images

Machine Parts

Name: Roller

Brand: Chengda

Original: China, Shandong

Flat die adopt high quality wear-resisting alloy steel, which are processed by special heat treatment, high hardness, long working life. It is recommended replace roller and die at the same time.

Main Parts

Name: Die
Brand: Chengda
Original: China, Shandong
We have several diameter for your choose, and the size can be customized according to your requirements. The raw materials also made of high quality wear-resisting alloy steel.high quality alloy steel material, you can choose 2.5mm,3mm,4mm,5mm,6mm,8mm,10mm according to your demand.

Our Service

1. 1 year guaranteed time with life-time service.
2. Free training, Guidance Installation and Debugging.If needed, engineers can be sent to your factory for installation and commissioning, training.
3. English manual and video for installation & operation.
4. Any problem in operation or others about the machine, you can contact with us we will give solution in 24-48 hours.

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
145*62*115cm
Weight
630/660kg



Packaging Details
Strong plywood case as exported standard, if your order is big we suggest shipping by container, we will calculate the total volume of your order and saving shipping cost for you.

Shipping: By sea, By air; Express (DHL/FedEx; Railway; Highway)
Our Company

Laizhou Chengda Machinery Co., Ltd

Laizhou Chengda Machinery Co., Ltd was founded in 1992, which is a high tech that enterprise integrates new product design, development, manufecturing and international trade business.
Main products: flat die pellet mill, vertical ring die pellet mill, wood chipper, hammer mill, pellet cooler and cutting wood machine etc.. Please free free to contact us if you have any inquiries and we will try our best to meet your demands.
