Rebar Roller Threading Machine YGS-40B With Factory Price
Specifications
roller threading machine:1. process straight thread
2. Cutting tools adopt automatic opening-closing device
Rebar roller threading machine YGS-40B with factory price
1. roller threading machine specification:
Name |
roller threading machine |
Model |
YGS-40B |
Rebar diameter |
φ12-φ40mm |
Power |
4KW |
Voltage |
3N 380V/50HZ |
Main shaft speed |
40-62r/min |
Max rolling length |
100mm |
Overall size |
1100*480*1040mm |
Net weight |
420kg |
Types of Rollers |
Big |
Middle |
Small |
Diameter of Rebar Processing |
14-22 |
25-32 |
36-40 |
Thread Pitch |
2.5 |
3.0 |
3.5 |
2. roller threading machine details:
3. screw rolling machine structure:
♥ This roller threading machine is made up of frame, clamping pliers, guide rail, skateboard, cycloidal reducer, cooling system, electrical control box etc.
4. How to get this roller threading machine:
5. Any question about the roller threading machine, please ask us at any time.♥♥♥
