Specifications
top quality hopper bubket elevator price1. Stable elevating process
2. low noise
3. simple to maintain.
Top quality hopper bucket elevator price
Brief Introduction of ElevatorBucket
Bucket elevator is to convey powder,granules and small lump materials whose piling density is less 1.5T/M3 and temperature is below 250°C. The conveying hopper volume is large enough to satisfy the general fertilizer production lines. It adopts chains structure and can conveys stably.
Features of hopper bucket elevator
1.Elevator rack is made of superlative steel,durable.
2.The fertilizer granules temperature should below 250°C.
3.The middle machine rack has single and double channels.
4.Stable elevating process,low noise,simple to maintain.
5.Large conveying capacity, 30% higher than the common elevator.
6.The chain is welded from alloy steel and disposed by carburization and quenching, good extension and wear-resisting ability.
Technical Data of hopper Bucket elevator
Model |
MG315 |
MG400 |
MG500 |
MG600 |
||||
Hopper type |
ZH |
SH |
ZH |
SH |
ZH |
SH |
ZH |
SH |
Conveying volume |
35L |
59L |
58L |
94L |
73L |
118L |
114L |
185L |
Hopper volume |
3.75L |
6L |
5.9L |
9.5L |
9.3L |
15L |
14.6L |
23.6L |
Hopper distance |
512mm |
688mm |
||||||
Round-steel(diameter*pitch) |
18*64mm |
22*86mm |
||||||
Strength of the single chain(kn) |
320 |
480 |
||||||
Unit pulling weight(kg/m) |
25.64kg/m |
26.58kg/m |
31.0kg/m |
31.9kg/m |
41.5kg/m |
44.2kg/m |
49.0kg/m |
52.3kg/m |
Rotating speed of the driving chain wheel |
42.5rpm |
37.6rpm |
35.8rpm |
31.8rpm |
||||
Max size of the material |
35mm |
40mm |
50mm |
60mm |
||||
Speed of the hopper |
1.4m/s |
1.5m/s |
||||||
Remarks: ZH stands for middle-deep hopper; SH standards for deep hopper.
Picture of hopper bucket elevator
