Help CenterHengyu Brand 3-D Standard Carbon Steel Vibration Screen Machine
Related Products
-
Hengyu Brand Multi-functional High Frequency Vibrating ScreenUS$ 1,500 - 4,500MOQ: 1 Set -
Hengyu Brand Edged Series High Quality Circular Vibrating ScreenUS$ 1,150 - 3,500MOQ: 1 Set
-
Linear Type Vibrating Sieve for PariclesUS$ 400 - 4,500MOQ: 1 Set
-
Vibrating Screen SeparatorUS$ 800 - 6,500MOQ: 1 Set
-
Drum Type Soil Screening MachineUS$ 600 - 4,500MOQ: 1 Set
vibration screenvibration screen :
duct upon customization
2.Sophisticated screening structure
3.low price
4.ISO9001:2000
Application of vibration screen
Widely used in sieving and filtering of powder, grains and serum in various industries,such as food, paper-making industry, chemical industry, pharmaceutical industry, grinding, ceramic industry, metallurgy, mining, electronic industry etc.
Features of vibration screen
1. Having the unique design of screen mesh, change it conveniently only 3-5 minutes;
2. Sophisticated machine, easily install, one can operate;
3. Largely effective area, high efficiency;
4. Can be installed by one to five layers; can sieve different materials;
5. High quality of screen mesh, long service life, low-production cost.
Technical Parameters of vibration screen
|
Model |
Power(KW) |
Diameter of screen surface(mm) |
Dimensions(mm3) |
layer |
|
|
HY-400 |
-1S |
0.18 |
350 |
580×580×560 |
1 |
-2S |
580×580×670 |
2 |
|||
-3S |
580×580×780 |
3 |
|||
|
HY-600 |
-1S |
0.25 |
550 |
800×800×750 |
1 |
-2S |
800×800×890 |
2 |
|||
-3S |
800×800×1030 |
3 |
|||
|
HY-800
|
-1S |
0.55 |
750 |
900×900×750 |
1 |
-2S |
900×900×890 |
2 |
|||
-3S |
900×900×1030 |
3 |
|||
|
HY-1000 |
-1S |
0.75 |
920 |
1160×1160×810 |
1 |
-2S |
1160×1160×950 |
2 |
|||
-3S |
1160×1160×1090 |
3 |
|||
|
HY-1200 |
-1S |
1.10 |
1120 |
1360×1360×885 |
1 |
-2S |
1360×1360×1050 |
2 |
|||
-3S |
1360×1360×1275 |
3 |
|||
|
HY-1500 |
-1S |
1.50 |
1420 |
1850×1850×990 |
1 |
-2S |
1850×1850×1185 |
2 |
|||
-3S |
1850×1850×1380 |
3 |
|||
|
HY-1800 |
-1S |
2.20 |
1720 |
2200×2200×1050 |
1 |
-2S |
2200×2200×1250 |
2 |
|||
-3S |
2200×2200×1450 |
3 |
|||
