Stainless Steel 304 Single Deck Starch Sifter

Stainless Steel 304 Single Deck Starch Sifter thumbnail-1
Stainless Steel 304 Single Deck Starch Sifter photo-1
US$ 2,300 - 7,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HENG SHUN
Model Number:
HY-BZ-1000-1S
Contact Supplier Request Quote Chat Now
Xinxiang Hengyu Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name HENG SHUN
Model Number HY-BZ-1000-1S
Type Grain Processing Equipment



   Stainless steel 304 single deck starch sifter

 Stainless steel 304 single deck starch sifter



Hengyu brand starch sifter mostly useful

Where's Quality is important than Capacity.

 Hengyu brand starch sifter are well designed to suitable

 for Capacity 100 kgs/hr to 22000 kgs/hr.

Machine models are available from 600mm to 1800mm diameter. Wecan provide 1 layer to 4 layers.



Some differences compared with others:



• The thickness of our sieve frame is 2.0mm stainless steel 304 or 316L.
• Stainless steel 304 sieves with long service life. ( Saving in replacement cost of wire mesh)
• Self-cleaning device, no blocking.

• Silica gel bouncing balls, and Nylon ring, up to food grade.

• Power as your request.
• IP55 protection level motor or lubrication free motor as request.
• ISO 9001:2008, CE and BV Certificates.
• Special customization is accepted.

Function as follows:

Remove impurity from powder

 Stainless steel 304 single deck starch sifter

This application is useful to remove foreign particles from desire
material, removal of lumps from powder, separate different size
of material, to remove over size of material.

Solid - Liquid Seperation

 Stainless steel 304 single deck starch sifter

Removal of solid from liquid, baggass from sugar or juice,

pulp from water, lumps from slurry,

to take desire size of particles in ceramic slurry, chocolate liquid





Specifications:



According to your different capacities, seven models machine can be offered,



Model

Power( kw)

Effective diameter

Effective screening area

Dimensions(mm)

layer



HY-400

-1S



0.18



360 mm



0.10 m2

580×580×560

1

-2S

580×580×670

2

-3S

580×580×780

3



HY-600

-1S



0.25-0.55



560 mm



0.246 m2

800×800×750

1

-2S

800×800×890

2

-3S

800×800×1030

3



HY-800

-1S



0.55-0.75



760 mm



0.453 m2

900×900×750

1

-2S

900×900×890

2

-3S

900×900×1030

3



HY-1000

-1S



0.75-1.5



930 mm



0.679 m2

1160×1160×810

1

-2S

1160×1160×950

2

-3S

1160×1160×1090

3



HY-1200

-1S



1.10-1.75



1130 mm



1.002 m2

1360×1360×885

1

-2S

1360×1360×1050

2

-3S

1360×1360×1275

3



HY-1500

-1S



1.50-2.20



1430 mm



1.605 m2

1850×1850×990

1

-2S

1850×1850×1185

2

-3S

1850×1850×1380

3



HY-1800

-1S



2.20-3.0



1730 mm



2.349 m2

2200×2200×1050

1

-2S

2200×2200×1250

2

-3S

2200×2200×1450

3



Your special customization is accepted,

Choose us, good sieving result for you.
