High Crushing Ratio 600*900 Stone Jaw Crusher for Calcite

Specifications

600*900  Stone Jaw Crusher for Calcite

Main Specifications  of 600*900 Stone Jaw Crusher for Calcite

(1) Max feeding size: 500 mm

(2) Discharge opening range: 65-160mm

(3) Capacity: 50-180 t/h

(4) Motor power: 55 kw

(5) Total weight: 17 t

(6) Dimensions(L*W*H)(mm): 2190*2206*2300

 Introduction of 600*900 Stone Jaw Crusher for Calcite

Jaw Crusher, a type of  jaw crusher,  has the features of high crushing and even product size ratio. It can be used to crush material, whose compression strength is not more than 320Mpa. PE Series is used in primary crushing, while PEX series is used in secondary crushing and fine crushing.

Features and Benefits of 600*900 Stone Jaw Crusher for Calcite

Simple structure and reliable operation
Easy maintenance and low operating cost

Operating Principle of 600*900  Stone Jaw Crusher for Calcite

Jaw Crasher is driven by motor.  Through the motor’s wheels, the eccentric shaft is driven by the triangle belt and slot wheel to make the movable jaw plate move by a regulated track. Therefore, the materials in the crushing cavity composed of fixed jaw plate, movable jaw plate and cheek plate can be crushed and discharged through discharging opening.

 Zhengzhou Unique Industrial Equipment Co., Ltd, a reliable and professional supplier of  600*900 Stone Jaw Crusher for Calcite
