High Crushing Ratio Concrete Impact Crusher for Sale
- 80 Set / Sets per Month
- Qingdao; Shanghai; Tianjin etc.
- T/T
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Impact Crusher | Motor Type: | AC Motor |
Power(W): | 110kw | Capacity(t/h): | 70-130 | Place of Origin: | Henan, China |
Brand Name: | UNIQUE | Model Number: | PF 1210 | Dimension(L*W*H): | 2680*2160*2800mm |
Weight: | 17.7t | Certification: | CE, ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Application: | Granite, Marble, Quartz, Basalt etc. |
Product Description
Specifications
Concrete Impact Crusher1. Long service life;
2. High reduction ratio;
3. Energy saving;
High Crushing Ratio Concrete Impact Crusher for Sale
Features of Concrete Impact Crusher
Concrete impact crusher, a type of Impact Crusher is mainly used in secondary crushing. It can crush various rocks, high efficiency, easy maintenance, and cubic shape of the products. Impact crusher is widely used in mining, highway, and construction.
Working Principle of Concrete Impact Crusher
Impact crusher 's electric motor drive the rotor to high speed, when the material was fed to the crushing chamber from feed inlet, the material will be struck by the plate hammer on the rotor, then will be thrown to the impact plates, after struck repeatedly, the final products will be discharged from the crusher.
Technical Specification of Concrete Impact Crusher
Model | Max Feed Edge(mm) | Capacity (t/h) | Motor Power (kw) | Weight (t) | Dimensions (L×W×H) (mm |
PF-1007 | 300 | 30-70 | 45 | 12 | 2330×1660×2300 |
PF-1010 | 350 | 50-90 | 55 | 15 | 2370×1700×2390 |
PF-1210 | 350 | 70-130 | 110 | 17.7 | 2680×2160×2800 |
PF-1214 | 350 | 100-180 | 132 | 22.4 | 2650×2460×2800 |
PF-1315 | 500 | 130-250 | 220 | 27 | 3180×2720×2620 |
Impact Crusher Structure |
