Portable Concrete Mix Plant With Chassis That Can be Moved From One Size to Another
- Qingdao
- T/T Money Gram Credit Card
You May Like
-
Hight Quality YHZS60 Concrete Batching Plant With Portable Chassis
-
YHZS60 Concrete Mobile Plant With Belt Conveyor and Auto Weighting System
-
Large Capacity Electric Mobile Concrete Batching Plant With JS1000
-
High Quality YHZS60 Mobile Cement Mixing Plant for Sale in Philippines
-
Best Sale Mobile Cement Batching Plant With PLC and Computer
-
YHZS60 Ready Mixed Concrete Mobile Plant Sold to South Africa
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Henan, China | Brand Name | UNIQUE | |
| Model Number | YHZS60 | Power(W) | 70kw | |
| Dimension(L*W*H) | 17.7*3.6*8.2 | Weight | 25T | |
| Certification | CE Certificate | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Portable concrete mix plant with chassis that can be moved from one size to another
Portable concrete mix plant is widely used for construction projects' concrete mixing, the concrete mixer is new designed spiral compound blades concrete mixer, the aggregate supply is with belt conveyor, the aggregate batching system can be 2 bins or 4 bins, with auto weighting, fully auto-control with SIEMENS brand PLC.
The portable concrete mix plant is widely sale in Philippines, South Africa, Russia, Australia, Greece, Sri Lanka and etc. countries.
Specification of YHZS60 portable concrete mix plant
Main Parameter | Model | YHZS60 |
Capacity | 50-60m3/h | |
Dimension | Working: 17.7*3.6*8.2m | |
Transport: 18.3*2.4*4.35m | ||
Discharging Height | 3800m | |
Max Drag Speed | 40km/h | |
Total weight | about 25t | |
Installed Power | about 70Kw | |
Concrete Mixer | Model | JS1000 |
Capacity | 50m3/h-60m3/h | |
Charging Volume | 1600L | |
Discharging Volume | 1000L | |
Motor Power | 2*18.5 Kw | |
Aggregate Dameter | 60-80mm | |
Aggregate Batcher | Model | PLD1600 |
Capacity | ≥80m3/h | |
Storage Silo No. | 4 | |
Storage Silo Volume | 6m3 | |
Max. Measuring Capacity | 4000kg | |
Batching Precision | ±2% | |
Belt Conveyor | Belt conveyor Angle | 26° |
Belt Width | 650mm | |
Belt Power | 11kw | |
Weighting System | Sandstone Precision | 4000kg±2% |
Cement Precision | 720kg±1% | |
Water Precision | 360kg±1% | |
Additive Precision | 36kg±1% | |
Air System | Air Compressor | 4Kw |
Rated pressure | 1.0 Mpa | |
Volume of emission | 0.7m3/min | |
Volume of emission | 0.32m3/h | |
Screw Conveyor Optional | Model | LSY219 |
Capacity | 25t/h | |
Diameter | 219mm | |
Power | 10kw | |
Length | 8m | |
Cement Silo Optional | Capacity | 100T |
Arch breaking device | V2FS250GBN | |
Dust Wiper | 1set | |
Level measure device | VFS |
For the portable concrete mix plant:
Packaging: standard package for exporting
Shipping:usually 3 pcs 40HQ containers are needed, without optional parts.
1. 12months waranty for the portable concrete mix plant.
2. Engineer can be assigned to guide installation and commission for the mobile concrete plant for sale.
3. After-sales engineers are available for 24hours/7days.
4. Spares parts are always in stock.
UNIQUE is a professional construction machinery manufacturer for over 30 years, with exporting the machines to over 60 countries and areas within the past 10 years, products include concrete mixer, stationary concrete batching plant, portable beton plant, cocnrete truck mixer, cocnrete pump, concrete block making machine and etc.
Burt Kong(Mr.)
Sales manager
Tel:0086 371 63699132
Fax:0086 371 63935058
Mobile:0086 151 3713 7329
Whatsapp: 0086 151 3713 7329
BBM PIN:79D3556E
Skype: Burt Kong
