Environment Friendly Mobile Concrete Plant Made in China for Sale

Name: Environment Friendly Mobile Concrete Plant Made in China for Sale
Brand: UNIQUE
Availability: InStock

FOB Price

US$ 50,000 - 200,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Henan, China	Brand Name	UNIQUE
Model Number	YHZS60	Power(W)	70kw
Dimension(LWH)	17.73.68.2	Weight	25T
Certification	CE Certificate	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Environment friendly mobile concrete plant made in China for sale

Product Description

YHZS60 mobile concrete plant for sale is widely used for construction projects' concrete mixing, the concrete mixer is new designed spiral compound blades concrete mixer, the aggregate supply is with belt conveyor, the aggregate batching system can be 2 bins or 4 bins, with auto weighting, fully auto-control with SIEMENS brand PLC.

The mobile concrete plant for sale is widely sale in Philippines, South Africa, Russia, Australia, Greece, Sri Lanka and etc. countries.

Specification of YHZS60 mobile concrete plant for sale

Main Parameter	Model	YHZS60
	Capacity	50-60m3/h
	Dimension	Working: 17.73.68.2m
	Dimension	Transport: 18.32.44.35m
	Discharging Height	3800m
	Max Drag Speed	40km/h
	Total weight	about 25t
	Installed Power	about 70Kw
Concrete Mixer	Model	JS1000
	Capacity	50m3/h-60m3/h
	Charging Volume	1600L
	Discharging Volume	1000L
	Motor Power	2*18.5 Kw
	Aggregate Dameter	60-80mm
Aggregate Batcher	Model	PLD1600
	Capacity	≥80m3/h
	Storage Silo No.	4
	Storage Silo Volume	6m3
	Max. Measuring Capacity	4000kg
	Batching Precision	±2%
Belt Conveyor	Belt conveyor Angle	26°
	Belt Width	650mm
	Belt Power	11kw
Weighting System	Sandstone Precision	4000kg±2%
	Cement Precision	720kg±1%
	Water Precision	360kg±1%
	Additive Precision	36kg±1%
Air System	Air Compressor	4Kw
	Rated pressure	1.0 Mpa
	Volume of emission	0.7m3/min
	Volume of emission	0.32m3/h
Screw Conveyor Optional	Model	LSY219
	Capacity	25t/h
	Diameter	219mm
	Power	10kw
	Length	8m
Cement Silo Optional	Capacity	100T
	Arch breaking device	V2FS250GBN
	Dust Wiper	1set
	Level measure device	VFS

Packaging & Shipping

For the YHZS60 mobile concrete plant for sale:

Packaging: standard package for exporting

Shipping:usually 3 pcs 40HQ containers are needed, without optional parts.

Our Services

1. 12months waranty for the mobile concrete plant for sale.

2. Engineer can be assigned to guide installation and commission for the mobile concrete plant for sale.

3. After-sales engineers are available for 24hours/7days.

4. Spares parts are always in stock.
