2013 Small Bal Mill Supplier

2013 Small Bal Mill Supplier thumbnail-1
2013 Small Bal Mill Supplier photo-1
US$ 5,600 - 66,666 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Zhengzhou Unique Industrial Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao; Shanghai; Tianjin etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Motor Type AC Motor
Capacity(t/h) 3.1-82
Place of Origin Henan, China
Brand Name UNIQUE
Model Number 1500*3000,2200*7500,2200*7000,2200*6500
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Small Bal Mill Supplier:
1. For cement, silicate, gypsum, limestone etc.
2. Wet or dry ball mill;

2013 Henan Small Bal Mill Supplier
2013 Small Bal Mill Supplier

Working Principle of Henan Small Ball Mill

Ball Mill, is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials.



2013 Small Bal Mill Supplier

Specification  of  Henan Small Ball Mill

Type

Model

drum (mm)

volume (m3)

revolution (r/min)

motor (KW)

discharging size (mm)

Output (t/h)

Wet-Grate

Ball

Mills

MQ1530

1500×3000

4.5

26.5-29.8

95

0.3-0.074

6.1-3.1

MQ2130

2100×3000

9.2

22.2-25.2

210

0.3-0.074

14-6.4

MQ2430

2400×3000

12.2

20.8-23.5

240

0.3-0.074

18.5-8.7

MQ2736

2700×3600

18.4

19.6-22.2

400

0.3-0.074

28-13

MQ3245

3200×4500

32.8

18-20.4

800

0.3-0.074

49-24

MQ3660

3600×6000

54.4

17-19.2

1600

0.3-0.074

82-38

Dry-Grate Ball

Mills



MQG1515

1500×1500

2.2

26.5-29.8

60

0.4-0.074

5.2-1.9

MQG1522

1500×2250

3.4

26.5-29.8

75

0.4-0.074

10.2-2.7

MQG1530

1500×3000

4.5

26.5-29.8

95

0.4-0.074

14-3.6

MQG2122

2100×2200

6.7

22.2-25.2

155

0.4-0.074

25-5

MQG2424

2400×2400

9.8

20.8-23.5

210

0.4-0.074

29-7.5

MQG2430

2400×3000

12.2

20.8-23.5

240

0.4-0.074

38-9.5

Over-flow Ball

Mills



MQY1530

1500×3000

4.5

26.5-29.8

95

0.3-0.074

6-2.8

MQY2136

2100×3600

11

19-25.2

210

0.3-0.074

12.8-6

MQY2430

2400×3000

12.2

17.8-23.5

240

0.3-0.074

16.6-7.8

MQY2740

2700×4000

20.4

16.8-22.2

400

0.3-0.074

27.7-13

MQY3254

3200×5400

39.4

15.5-20.4

1000

0.3-0.074

52.8-25.9

MQY3660

3600×6000

54.4

14.5-19.2

1250

0.3-0.074

74.1-32.4



2013 Small Bal Mill Supplier



2013 Small Bal Mill Supplier



Zhengzhou Unique Industrial Equipment Co., Ltd, a reliable and professional supplier of  Henan Small Ball Mill
