Zhengzhou UNIQUE Brand KG940A Stone Crawler Drill
Safe and Stable Travelling System of KG940A Stone Crawler Drill
1. This machine has low gravity center and big ground clearance, and can easily travel on bumpy road. It is driven by special wheel motor. That brings it strong grade-ability and low failure rate.
2. Equipped with advanced auto-balance and brake system, makes the moible drilling rig travel stably and also greatly reduce its impact force to ensure the drive safety.
3. Special anti-lock device greatly improves the crawler rock drill’s reliability.
4. Vehicle-mounted diesel engine provides strong power, so the mobile drilling rig can freely travel without air compressor.
Powerful and Reliable Engine o f KG940A Stone Crawler Drill
1. Adopt famous 4-cylinder diesel engine as driving force which has advantages of large power, small volume, small vibration and reliable operation.
2. Adopt patent diesel engine air inlet regulating device (Patent No. : 200820087606.3) and desert air filter three-stage filter. That strengthens the mobile drilling rig’s adaptability to severe environment and lengthened the diesel engine’s service life.
New Drilling boom of KG940A Stone Crawler Drill
1. Optimally designed luffing mechanism and round drilling boom with the advantages of neoteric structure and easy maintenance greatly improves the drilling hole’s coverage area. That also makes low-order horizontal hole drilling available.
Powerful Feed Mechanism and Rotating System of KG940A Stone Crawler Drill
1. The new rotating system is composed of orbit hydraulic motor and planetary gearbox. That provides the crawler rock drill with strong torque reserve and reduce the sticking drilling rate.
2. The feed mechanism driven by high power hydraulic motor can generate 20 KN lifting power. Adjust the pressure regulating valve on the control valve can got the favorable driving power which is required by the working condition.
Specification of KG940A Stone Crawler Drill
|
Model
Specification |
KY140 |
Rock hardness |
F=6-20 |
Hole diameter(mm) |
105-140 |
Drill depth(m) |
25 |
Pressure (Mpa) |
1.0-2.4 |
|
Air consumption (M3/min) |
≥15 |
Rotating speed (Km/h) |
0-63 |
Lifting capacity (KN) |
20 |
Drill rod specification(mm) |
76×3000 /89×3000 |
Gradeability |
30° |
|
Ground clearance(mm) |
320 |
Walking speed (km/h) |
2.0 |
Drill arm rising angles (°) |
-15~+50 |
Drill arm swing angle (°) |
±45 |
Carriage swing angle(°) |
±50 |
Carriage pitch angle (°) |
180 |
Carriage Compensation(mm) |
1200 |
|
Overall Dimension (L*W*H)(mm) |
5850×2250 ×2020 |
Total Weight (Kg) |
5500 |
Note: |
Pneumatic -hydraulic |
Specification of Mobile Screw Air Compressor
Model |
Work pressure |
Capacity |
Diesel engine (hp) |
Weight |
Dimension |
LGCY-12/10 |
1.0 |
12 |
YuChai |
3500 |
3600*1900*2200 |
LGCY-13/13 |
1.3 |
13 |
Cummins |
3500 |
3600*1900*2200 |
LGCY-15/13 |
1.5 |
15 |
YuChai |
3500 |
3600*1900*2200 |
LGCY-18/17 |
1.7 |
17 |
Cummins |
3500 |
3600*1900*2200 |
