Labor saving active carbon making machine
Contact person:Winnie
Skype:taizy2019
QQ:1799244239
Mobile/whatsapp/wechat:0086-18703616826
Main introduction of active carbon making machine
(1) Outer stove
includes heating room (for heating the inner stove), furnace body and heat-keeping layer (it is made of the heat insulating material)
(2) Inner stove
Consist of the stove tank body and the sealed top cap. Both of them are made of the heat resistance thermal steel, three inner stove can be stacked together for saving space and shipping cost.
(3) Smoking recycle tube
During the process of carbonizing, there will be some smoke.( can be burning) the smoke can be collected and returned to the furnace.
(4) Purification tank
This system is consisting of purification tank and the exhaust-heated cycle pipe.
(5) Hoisting equipment
it include the steel hoisting frame and the E-hoist .And it is easy for loading and unloading the stove.
Parameter of active carbon making machine
Model |
Weight |
Capacity |
Diemension |
TZY-3 |
2t |
180kg |
2900*1400*2000mm |
TZY-4 |
2.5t |
300kg |
3500×1500×2000mm |
4t |
600kg |
4000×1500×2000mm |
|
5t |
1000-1200kg |
5000×1600×2200mm |
The final product of active carbon making machine
packing of active carbon making machine
