Easy Maintenance and Operation Wood Crusher Grind
Crushing is the first and also the important step to concern. There are two types of wood crushing machine available for make suitable size sawdust .The choice of proper model depends on the types and size of your raw material.Wood crusher is designed to crush wood branches,twigs,limbs as well as cellulosic stalk materials like bamboo,couch grass,corn stalk,sorghum stalk,etc.
| Model No. | Power | Output(kg/h) | Sieve screen size | Sieve screen specification | Packing Size(mm) |
| WDCF158 | 2.2kw | 60-120 | 360*160mm | 1.5-10mm | 480*580*630 |
| WDCF158 | 2.2kw | 60-120 | 360*160mm | 1.5-10mm | 480*580*630 |
| WDCF198 | 4kw | 200-300 | 510*200mm | 2-10mm | 900*580*1020 |
| WDCF420B | 3 phase 7.5kw | 200-400 | 680*280mm | 1.8-10mm | 1120*820*1070 |
| WDCF420C | 3 phase 11kw | 200-500 | 680*280mm | 2-10mm | 1120*820*1070 |
| WDCF420A | 15HP Diesel engine | 300-500 | 680*280mm | 1.8-10mm | 1470*730*1090 |
| WDCF420A | 22HP Diesel engine | 300-500 | 680*280mm | 1.8-10mm | 1470*740*1110 |
| WDCF500A | 55HP Diesel engine | 800-1100 | 820*390mm | 2-10mm | 1500*1420*1230 |
| WDCF500B | 22kw | 800-1100 | 820*390mm | 2-10mm | 1240*970*1060 |
Large Capacity Wood Crusher (Hammer mill and Wood Chip Crusher)
Similar Machines(wood chip crusher)
1.Our wood grinder combines both chipping and crushing, so there is no need to use wood chipper for pre-processing of wood logs. it can crush both hard wood and soft wood with diameter range from 100 to 350 mm.The output by this machine is sawdust which can be further made as wood pellets.
2.Adopts international famous bearing which can guarantee a long working life a reliable operation.Hammer blades are made of high manganese steel.
3.Highly eco-friendly and energy-saving.
working principle: because of knives cutting and high speed airflow impact, wood materials are smashed and crushed and can be screened at the same time. During knives cutting, rotors rotates along with knives cutting direction and creates high speed airflow.Wood materials speed up to be smashed and at last crushed to the required size.
Final Products After Being Crushed
Zhengzhou Whirlston Machinery Co.,LTD is one of the biggest export enterprises in middle of China. We have specialists on technology, sales, design and afer-service.
Our company has established friendly business relationships with customers in Russia,German,Slovakia, Ukraine,Vietnam,Pakistan, the Philippines, Indonesia, Thailand,
Pakistan, Egypt ,Iraq, Iran,Jordan,Saudi Arabia,Syria, Libya,South America,East European etc.
No Regrets To Buy and No Worry After Buy
