Wood Pellet Hammer Mill With Screen Hole Diameter 1.8mm-10mm
Hammer Mill For Sale Introduciton
Crushing is the first and also the important step to concern. There are two types of wood crushing machine available for make suitable size sawdust .The choice of proper model depends on the types and size of your raw material.Wood crusher is designed to crush wood branches,twigs,limbs as well as cellulosic stalk materials like bamboo,couch grass,corn stalk,sorghum stalk,etc. It is suitable to crush wood material with diameter of 50-200mm and width of 200mm. For wood material with diameter of less than 50mm,you can choose wood hammer mill.
Highlight Of the Hammer Mill
1. The diesel engine and motor crusher are available, it is suitable for making wood pellet stove pellets for your own family.
2. Both coarse and fine grinding can be realized through adjusting the gap between hammers and screen. So processing feedstuff material is also possible.
3. The core part ---the hammer flake is scientifically designed to have two concussion parts, thus when one part is worn out, you can turn over to use the other part.
4. The angle of the screen can be 180° which allows for high throughput at lower power consumption.
5. Equipped with air blower, the crushed material can be directly collected and transported to next machine for further processing.
6. You can change screening sieve according to different material grinding requirements.
7. We can customize the following sieve with screening hole diameter of 1.8mm-10mm.
Technical Data of Hammer Mill For Sale
| Model | Production Capacity | Screen Size |
Overall dimension | Power |
| WR 158 |
60-120kg/h | 1.5-10mm | 480*580*630mm | 2.2KW |
| WR 198 |
200-300kg/h | 2-10mm | 900*580*1020mm | 4KW |
| WR 198 | 200-300kg/h | 2-10mm | 960*620*1050mm | 7.5HP diesel engine |
| WR 420B | 200-400kg/h | 1.8-10mm | 1120*820*1070mm | 7.5kw |
| WR 420C | 200-500kg/h | 2-10mm |
1120*820*1070mm | 11kw |
| WR420A |
300-500kg/h |
1.8-10mm | 1470*730*1090mm | 15HP |
| WR420A | 300-600kg/h | 1.8-10mm | 1470*740*1110mm | 22HP |
| WR500A |
800-1100kg/h |
2-10mm | 1500*1420*1230mm | 55HP |
| WR500B | 800-1100kg/h | 2-10mm | 1240*970*1060mm | 22kw |
| Model | Production Capacity | Blade Length |
Blade number | Overall dimension | Power |
| WR 400 |
300-500kg/h | 95mm | 4pcs | 1100*700*950mm | 7.5kw |
| WR 600 | 600-700kg/h | 180mm | 4pcs | 1500*800*1200mm | 15kw |
| WR 800 | 800-1200kg/h | 260mm | 6pcs | 2100*1100*1400mm | 30kw |
| WR 1000 | 1800-2000kg/h | 300mm | 6pcs | 2100*1200*1600mm | 45kw |
Final Products After Being Crushed
Pellet Machines Are Available
Hammer Mill For Sale For Wood Features
1.Our wood grinder combines both chipping and crushing, so there is no need to use wood chipper for pre-processing of wood logs. it can crush both hard wood and soft wood with diameter range from 100 to 350 mm.The output by this machine is sawdust which can be further made as wood pellets.
2.Adopts international famous bearing which can guarantee a long working life a reliable operation.Hammer blades are made of high manganese steel.
3.Highly eco-friendly and energy-saving.
How to Crush Wood Material
Wood crusher works principle: because of knives cutting and high speed airflow impact, wood materials are smashed and crushed and can be screened at the same time. During knives cutting, rotors rotates along with knives cutting direction and creates high speed airflow.Wood materials speed up to be smashed and at last crushed to the required size.
Certificate of Hammer Mill
Zhengzhou Whirlston Machinery Co.,LTD is one of the biggest export enterprises in middle of China. We have specialists on technology, sales, design and afer-service.
Our company has established friendly business relationships with customers in Russia,German,Slovakia, Ukraine,Vietnam,Pakistan, the Philippines, Indonesia, Thailand,
Pakistan, Egypt ,Iraq, Iran,Jordan,Saudi Arabia,Syria, Libya,South America,East European etc.
No Regrets To Buy and No Worry After Buy
For more information,please contact me as soon as possible.
