Introduction
It is widely used for producing maize flour, soybean flour or compound powder, wheat bran into high
grade aquatic feed pellets for fish, catfish, shrimps, dog,.cat etc. The puffing fish feed pellets can floaton the water surface for over12 hours without water pollution. According to your requirement and
production scale, floating fish feed machine can be classified into dry type machine and wet type
machine.
Working Principle
After the material is sent into feeding device, they will be pressed by the screw shaft with high
pressure and temperature which makes the raw material fully cooked and sterilized. Then the pressed material will be formed into pellets by shaping mould. You can change different moulds to make
pellets with different diameters. After that a cutting device will cut the formed pellets into different
length as required.
Features
1. The puffing fish feed pellets can float on the water surface without dissolution for over 12 hours.
2. Various shapes feed pellet are available, superior quality fish feed pellet, shrimp feed pellet and
pet feed pellet can be produced.
3. The puffing time can be controlled according to the puffing degree adjustment.
4. The feed pellet diameter is customized 1.0-20mm by changing the mold.
5. The final product feed pellet is easy digest, and being cooked with high temperature and pressure, the salmonella and bacterial can be killed completely.
6. Pellet length is adjustable.
Technical Parameters
Model |
Main Power |
Screw diameter(mm) |
production capacity |
WDDGP50-C |
7.5-11KW |
50mm |
60-80kg/h |
WDDGP60-C |
15KW |
60mm |
100-150kg/h |
WDDGP70-B |
18.5KW |
70mm |
200-350kg/h |
WDDGP80-B |
22KW |
80mm |
250-300kg/h |
WDDGP90-B |
37KW |
90mm |
350-400kg/h |
WDDGP120-B |
55KW |
120mm |
500-600kg/h |
WDDGP135-B |
75KW |
135mm |
700-800kg/h |
WDDGP160-B |
90KW |
155mm |
1000-1200kg/h |
WDDGP200-B |
75KW |
195mm |
1800-2000kg/h |
WDDSP60-C |
15KW |
60mm |
150-200kg/h |
WDDSP70-B |
18.5KW |
70mm |
250-350kg/h |
WDDSP80-B |
22KW |
80mm |
400-500kg/h |
WDDSP80-B |
37KW |
90mm |
600-700kg/h |
WDDSP160-B |
90KW |
155mm |
1800-2000kg/h |
WDDSP200-B |
132KW |
195mm |
3000-4000kg/h |
Our Service
1. We provide 1 year guarantee with life-time service.
2. We provide English manual and video for installation & operation.
3. If required, we could send technicians for installation and commissioning, training.
4. Any problem in operation or others about the machine, you can contact with us we will give solution in 24-48 hours. If big problem, we can send technician to customer's local place.
