Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner

Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner photo-1
Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner photo-2
Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner photo-3
Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner photo-4
Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner photo-5
Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner photo-6
US$ 4,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
TN-ORIENT
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or Shanghai of China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name TN-ORIENT
Model Number FTL60-8000
Voltage 220V/380V
Power(W) 0.8kw
Weight 500kg
Dimension(L*W*H) 1200*500*1500mm
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner

Application of  Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner

Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner   is applicable to drying equipment, smelting furnace, heating boiler,alternative fuel(gas) burner and other equipment which need heating heat source, easy to use,safe and reliable.

Performance & Characteristics
1. Specifications of selected biomass pellet fuel: diameter 6-8mm, length 20-40mm.
2. Fluidized combustion:Ensure the combustion efficiency and flue gas standard.
3. Upper rotating feed: Unique feed method with simplified furnace structure. Ensure material uniform distribution, and fire smoke suppression and the secondary air distribution function.
4. Level wind: Ensure smooth discharge, the utmost to reduce the grate slagging rate.
5. Little slagging of furnace wall:whirlwind protection make the furnace wall little slagging, improve the working life of furnace and reduce the cleaning work.
6. Modular design: fast and reliable repair and replacement.
7. Long life: use heat insulation design for feed pipe, fire outlet and furnace door.
8. Air Cooling: Preheat air distribution, thermal efficiency increased by 5%
9. Fire Outlet Temperature: 800-1200°c



Commercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner

Commercial White Wood Burner/Function Bamboo Wood Burner/Wood BurnerCommercial White Wood Burner/Function Bamboo Wood Burner/Wood Burner






Model
Rated power (kw)
Fuel consumption (kg/H)
Rated Voltage(V)
Rated power consumption (kw)
Diameter of burner(mm)
Geocentric height(mm)
FTL60
60-100
13-22
220
0.8
160
600
FTL120
120-280
26-62
220
0.9
160
600
FTL500
500-750
110-160
220
1.5
200
800
FTL1200
1200-1550
266-344
380
2.2
380
800
FTL2400
2400-2950
533-655
380
2.2
500
1000
FTL3000
3000-4000
666-888
380
2.2
670
1130
FTL5000
5000-6900
1111-1500
380
3.55
670
1200
FTL6000
6000-7900
1333-1755
380
4.23
700
1200
FTL8000
8000-9000
1777-2200
380
4.50
800
1500
