Home > Products > New Products > sell well Concrete spraying machine /Cement mortar sprayer/Wall cement sprayer
sell well Concrete spraying machine /Cement mortar sprayer/Wall cement sprayer
- 2000 Set / Sets per Month
- Qingdao/Shanghai/Guangzhou
- T/T Credit Card PayPal
Product Details
Place of Origin: | Henan, China | Brand Name: | Furui | Model Number: | FR-5 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. Simple operation2. High efficiency, energy savable
3. Working with air compressor
4. Small size, movable
Construction shotcrete machine/ different type of the cement gunite machine / 3D wall concrete spraying machine
Shotcrete machine:
1. The machines set the advantages of wet and dry spray machine at home and abroad in one, it is easy to operate, sprays evenly. and has the advantage of a low dust, low rebound.
2. Non-adhesion going through rotor with new material chamber, completely eliminate bonding and blocking during operation so as to reduce clearance and maintenance period.
3. Four-point clamping device make it easy to adjust the press between sealing plate and rotor disk so as to no air and dust leak and prolong consumption parts life.,
4.Thin flow conveying method with vortex flow, so the spraying flow is even, continuous and steady, to improve the shotcrete quality.
Usage:
Shotcrete machine is widely used in engineering and construction, such as mining, tunnel, culvert, subway, hydropower engineering, underground excavation engineering etc.
spraying medium: cement, small rock, sand, water, etc. Many small medium less than 20mm is ok.
Main techincal date:
Model | Capacity | Air consumption | Conveying distance | Material ratio | Motor power | Max Aggregate size | Conveying pipe inner diameter | Weight |
FR-5 | 5 m3/h | 7-8 m3/h | 200m- 40m⊥ | 1:3-5 | 5.5kw | 20m | 51mm | 600kg |
FR-6 | 6-7 m3/h | 10-15 m3/h | 200m- 40m⊥ | 1:3-5 | 7.5kw | 20mm | 51/64mm | 800kg |
FR-7 | 7-8 m3/h | 10-15 m3/h | 200m- 40m⊥ | 1:3-5 | 7.5kw | 20mm | 51/64mm | 800kg |
FR-9 | 7-8 m3/h | 10-12 m3/h | 200m- 40m⊥ | 1:4-5 | 5.5kw | 15mm | 51mm | 1350kg |
Pictures of shotcrete machine:
Package detail: concrete shotcrete machine ncrete shotcrete machine standard free-fumigation case ncrete shotcrete machine standard export packing
Delivery detail: shotcrete machine within 7 days against down payment
If you have any interest in our shotcrete machine, please contact me freely.
Contact Person: Ms.Nina Zhang
Skype:freemachine2zu2014 Tel:0086-13523530615
Zhengzhou Furui Mechanical Equipment Co., Ltd. is a professional manufacturer of food making machines, industrial machines and agriculture machines in China.
We are a researching, manufacturing and trading integrated modern enterprise. And our brand-Furui, has been the well-known brand after outstanding development.
Our company has a professional testing center and a series of complete test and inspection equipment to ensure the quality. Several production bases are open for customers to visit.
We will be here look forward to cooperate with at competitive price and good quality. Welcome new and old customers to contact us for business negotiation.
