Scrap PCB electronic parts CPU IC chips recycling plant for gold recovery
This machine is used to deal with waste circuit boards to make further economic benefits. As we all know,there is much metal in circuit boards,such as copper(about 40%),gold,silver,nickel. The proportion of copper in circuit board is much more than that in mineral.
But the cost of recycling PCB to get copper is much less than that by mining. Printed circuit boards will cause environmental pollution and electronic waste without safe recycling. So this recycling machine can not only protect environment but also make high economic benefits. The raw material is scrap printed circuit boards(TV,cellphone,computer),copper-clad-boards. Its final product is copper and resin fiber powder.
Description:
The PCB recycling machine is used to recycle and separate the mental and non-mental part from the used circuit board and copper clad laminate. The output is mixed mental powder and resin powder.The whole line adopts 3-stage-crushing step to get mixed mental and resin powder. And then it separates mental and resin powder via air flow and high voltage electrostatic separator. Copper powder can be extracted from mixed mental powder via copper electrolysis system; In order to prevent dust pollution effectively,impulse dust collection performs before air flow separation. Our impulse dust collector can be customized as clients’ environmental-protecting requirements
Raw material:
1.Computer boards;
2.Cellphone boards;
3.TV boards
…etc.
Process:
1.PCB will be dismantled into electronic component and mother boards at first. Then put mother boards into crusher;
2.Rolling crusher is adopted in 1-stage-grinding to get pieces;
3.Hammer grinder is used in 2 and 3-stage-grinding to get mixed powder;
4.After crushing and grinding, the mixed powder will be separated into mental powder(90% copper) and resin fiber powder via air flow and high voltage electronic separator;
Features:
1.With compact structure, reasonable layout, stable performance, low noise;
2.Coordinate operation and even feeding with PLC in the whole line;
3.Large capacity to 1000kg/h via 3-stage-crusher;
4.Grinder with water cooling grinding;
5.Air flow separator with the separator rate over 99%;
6.The efficiency of impulse dust collection reached up to 99%;
7.Easy to replace wearing parts;
8.Finer and more efficient separation via high voltage electronic separator; Effectively controlling the loss of non-ferrous metals;
Technical Parameters:
Model |
Capacity(kg/h) |
Dimension(mm) |
Separation Rate |
Total Power(kw) |
Space needed(square meter) |
PCB-300 |
200-300 |
10000*5000*4100 |
99.8% |
45 |
50 |
PCB-500 |
400-500 |
15000*8000*4100 |
99.8% |
75 |
120 |
PCB-1000 |
800-1000 |
20000*15000*4100 |
99.8% |
160 |
300 |
Other processing system:
1.Dismantling Equipment:Dismantle electronic components from mother boards automatically,with exhaust gas processing system for environment protection.
2.Gold Stripping System with our patent technology:gold stripping chemical and gold reducing chemical;
3.Copper Electrolysis System:The copper metal powder we get will do copper electrolysis for getting 99.99% refine copper.
4.Precious Metal Refining System:To recovery precious metal(Au,Ag,Pd Pt) from electronic components and Anode slime in electrolysis tank.
Our company regards the product quality as the life of our enterprise. Our products have already passed relevant International Quality Management System Certifications. Our products are exported to clients across the world. We adopt highly abrasive materials and advanced processing technique, making the devices have long life span and wearproof performance. We have won a great reputation at home and abroad.
1. Where is your factory ?
Our factory is located in GongYi city and we have sales office in ZhengZhou city at the same time.It takes about 2 hours from XinZheng international airport to our factory and half an hour from the Airport to Our office.
2. Are you manufacturer or trade company ?
We are one manufacturer who have over 10 years experience in Solid Waste recycling machinery field.
We have our own factory, welcome to visit us and test our machine.
3. How does your factory do regarding quality control ?
Quality is life,Customer satisfaction is our pursuit.We keep strictly requirements about the quality with using X-Ray to test every section of the products, so we win customer reputation both at home and board.
4.What about your quality warranty?What u will do if there is some wrong with my machine in this period ?
Our products have 12 months quality warranty.We will send wear parts freely and dispatch our engineer to your country to repair it if need.
5. What about your delivery time ?
A. 10 days after received deposit if we have stock;
B. 15-20 days after received deposit if we need produce according to your request.
If you want to know more about the machine,please contact with Sophia:
