Professional Silica Sand Rotary Dryer from Henan

silica sand rotary dryer is mainly used in building materials, metallurgy, chemical plant, cement plant for drying of limestone slag, coal powder, slag, clay stone and so on. This dryer is formed by rotary body, lifting blade, driving device, supporting device and sealing ring. The silica sand rotary dryer  has advantages of reasonable structure, high efficiency, low energy consumption and convenient for transportation.





1. The internal adopts assembled structure which has improved the accuracy of the equipment and it is easy to transport and install.
 2. According to the characteristics of different fertilizers, we have arranged the second granulation zone reasonably so as to improve the granulation effect.
 3. Adopts assembled hoist board so as to exchange heat fully and lower the energy consumption.
 4. Temperature induction monitor, uniform vibration and airproof setting, which improve performance and productivity efficiently.
 5. The assorted combustion furnace is a type of energy-efficient and has the characteristics of smaller area, easy regulation and equipped with greenhouse.



Type   (mm)	Gradient (%)	Rotational speed (r/min)	Inlet air tempreture()	power (KW)	Pro-capacity (t/h)	weight (T)
Φ600x6000	3-5	3-8	≤700	3	0.5-1.5	2.9
Φ800x8000	3-5	3-8	≤700	4	0.8-2.0	3.5
Φ800x10000	3-5	3-8	≤700	4	0.8-2.5	4.5
Φ1000x10000	3-5	3-8	≤700	5.5	1.0-3.5	5.6
Φ1200x10000	3-5	3-8	≤700	7.5	1.8-5	14.5
Φ1200x12000	3-5	3-8	≤700	11	2-6	14.8
Φ1500x12000	3-5	2-6	≤800	15	3.5-9	17.8
Φ1800x12000	3-5	2-6	≤800	18	5-12	25
Φ2200x12000	3-5	1.5-6	≤800	18.5	6-15	33
Φ2200x18000	3-5	1.5-6	≤800	22	10-18	53
Φ2200x20000	3-5	1.5-6	≤800	30	12-20	56
Φ2400x20000	3-5	1.5-5	≤800	37	18-30	60
Φ3000x20000	3-5	1.5-5	≤800	55	25-35	78
Φ3000x25000	3-5	1.5-5	≤800	75	35-65	104.9
Φ3600x29000	3-5	1.3-5	≤800	110	40-70	150



Complete sets of equipment supply list:

1. rotary dryer: main rotary body,before roller ring,after roller ring,gear,pinion,input and output parts,reducer,motor, foundation bolt
2. layout plan drawing,foundation drawing of each machine

No	Name	Material	Qty	Remark
1	Cyclinder	Q345	1	Thickness:18mm
2	Rolling belt plate	A3	1
3	Bast plate for big gear wheel	A3	1
4	big gear wheel	GB45	1	inblock cast, heat treatment
5	Pinion	GB45	1	inblock cast, heat treatment
6	riding wheel	GB45	4	inblock cast
7	catch wheel	GB45	2	inblock cast
8	rolling ring	GB45	2	inblock cast
9	lifting blade	10mm	1	inblock cast
10	Motor	Yutong motor of Henan province	1
11	Bearing	Metallurgy bearing tile-roofed house	1
