High density material drum dryer
High density material drum dryer has good performance with reliable operation,good flexibility and adaptability,large drying
capacity.Drum dryer is suitable for granular material. Especially in drying of sand,drum dryer has excellent dry results.High
density material drum dryer usually is used for drying river sand,artificial sand,quartz sand,mine power,cinder,slag,etc.
Main technical parameters
Model(mm) |
Gradient (%) |
Rotating speed (r/min) |
Temperature (°C) |
Power (kw) |
Capacity (t/h) |
Weight (t) |
XSZ-600 |
3-5 |
3-8 |
≤700 |
3 |
0.5-1.5 |
2.9 |
XSZ-800 |
3-5 |
3-8 |
≤700 |
4 |
0.8-2.5 |
3.5 |
XSZ-1000 |
3-5 |
3-8 |
≤700 |
5.5 |
2.0-4.5 |
5.6 |
XSZ-1200 |
3-5 |
3-8 |
≤700 |
7.5 |
4-8 |
14 |
XSZ-1500 |
3-5 |
2-6 |
≤800 |
15 |
8-15 |
17.8 |
XSZ-1800 |
3-5 |
2-6 |
≤800 |
18.5 |
10-18 |
25 |
XSZ-2000 |
3-5 |
1.5-6 |
≤800 |
18.5 |
15-22 |
36 |
XSZ-2200 |
3-5 |
1.5-6 |
≤800 |
22 |
18-25 |
53.8 |
XSZ-2400 |
3-5 |
1.5-5 |
≤800 |
37 |
22-35 |
|
XSZ-3000 |
3-5 |
1.5-5 |
≤800 |
75 |
32-45 |
87.5 |
Note:the capacity has much to do with the heating mode for the dryer | ||||||
...
