Mesh belt dryer
Mesh belt dryer is a kind of batch,continuous production drying equipment,its mainly heating solution includes electric heating,
steam heating and hot air heating.The mesh belts are made by 12-60 mesh steel wires.The main principle is that the materials is spread uniformly on the mash-belts,transmission device will drive the mesh-belt into reciprocating movement inside the dryer.Meanwhile,the hot air will flow and touch the wet materials,the evaporating
steam will be discharged into air by special site,the dryer can be made into all the steam ar discharged,the material will
achieve the purpose of drying.In order to save the project site,the dryer can be made into multi-layers.The widely used dryer is 2 rooms with three layers or 2 rooms five layers,length is 6-40 m,effective width is 0.6-3.0 m.
Main technical data
|
Sec.
|
HJWD6 |
HJWD8 |
HJWD10 |
HJWD12 |
HJWD16 |
HJWD 20 |
HJWD24 |
HJWD30 |
Band width(mm) |
600 |
800 |
1000 |
1200 |
1600 |
2000 |
2400 |
3000 |
Dry section length(m) |
6-12 |
6-12 |
6-16 |
8-16 |
8-22 |
10-26 |
12-30 |
12-40 |
Feeding length(m) |
1 |
1 |
1 |
1 |
1 |
1.5 |
1.5 |
2 |
Transmission section length |
1 |
1 |
1 |
1 |
1 |
1.5 |
1.5 |
2 |
Dry area |
3.6-36 |
4.8-48 |
6-80 |
7.2-96 |
12.8-105.6 |
20-260 |
28.8-360 |
36-600 |
layer |
1-5 |
|||||||
Layer spacing(mm) |
400-600 |
|||||||
Carrying capacity |
90-200kg |
|||||||
Using temperature |
Carbon steel≤400°C,stainless steel≤600°C |
|||||||
Evaporation strength |
5-20kg water/.h |
|||||||
Heat source |
Hot air.electric.steam |
|||||||
Operation speed |
0.06-1m/min |
|||||||
Transmission power(kw) |
1.1-2.2 |
1.1-2.2 |
1.1-2.2 |
1.1-3 |
1.5-3 |
1.5-4 |
3-7.5 |
5-11 |
Auxiliary equipment |
Transportation equipment,hot air stove,dust removal equipment,induced draft fan,etc |
|||||||
....
Our Services
Pre-sale
1. Depending on customer's requirement, we insist on "making profit at lowest investment" and gives best solution as per the customer’s special demand.
2. Design the most reasonable project and maximum customers' profit.
3.Provide engineers to scene to plan work site if the customer needed.
4. Provide equipment list, design drawing, construction drawing, equipment install drawing.
During-sale
1. Depend on scene, draw design drawing , construction drawing, equipment install drawing, civil work detailed drawing for references, operating manuals, maintenance video, etc
2.Manufacturing products strictly on contract while customer constructing.
3. Production progress report each week with detailed description and photos, including raw materials tables, process and deep process record, testing data sheet, etc.
4. Testing all the equipments by witness of the customer ex-work, delivery, customer acceptance.
After-sale
1. Provide engineer to work site guiding install, debugging and commissioning.
2. Test equipment after installation, training operators for free, remind notice in operating.
3. Regularly returning visit to the customers.
4. Within warranted period, we take charge of everything if any quality problems. After the warranted period, we still focus on the plant running and services.
5. Response customer’s questions within 1 working day, give effective solutions within 3 working days, go into action with 5 working day.
That’s our promise, as we know quality and service both are important for long-term’s development and cooperation.
