Description of Rod Mill:
Rod Sand Making Machine can triturate wet or all kinds hard grade of ore and other material, especially can make many sizes sands. Rod Mill sand making machine is one sand gravel equipment in building industry, mainly for processing and crushing feldspar, quartz, ores and other raw materials.
Export country of the Rod Mill:
India,Vietnam,Kazakhstan,Mongolia,Ecuador,Iran,Pakistan,Australia,the Middle East and other countries and areas.
Working Principle of the Rod mill:
Cylinder rotate in a Specific speed, grinding body rise to fixed height then will be casted off under the effect of friction and centrifugal force , so that materials are impact grinding,achieve the purpose of the sand-making.
Features of Rod Mill:
Rod Mill has wide application range, its performance has reached the international advanced level, and it is the most effective, practical, and reliable sand-making equipment at present. The rod mill is especially applicable for the fine and middle crushing of such hard and fragile materials as sand for building (to crush such raw materials as the blue stone, limestone, scree and granite boulder into sand for building), abrasive materials, corhart, cement, quartz sand, steel sand, slag, powdery copper ore, iron ore, gold sand, aggregate of concrete and pitch and so on. The rod mill is a kind of high-efficient energy-saving crusher and sand maker, its energy consumption is 50% less the traditional sand-making equipment, and it is a kind of advanced sand-making equipment in the world.
Specifications of Rod Mill
Type |
Shell specifications(mm) |
Shell rotation speed (r/min) |
Feeder granul-arity(mm) |
Output granul-arity(mm) |
Processing capacity(t/h) |
Power(kw) |
Weight((kg) |
|
Dia. |
Length |
|||||||
MBS0918 |
900 |
1800 |
36-38 |
≤25 |
0.833-0.147 |
0.62-3.2 |
18.5 |
4600 |
MBS0924 |
900 |
2400 |
36 |
≤25 |
0.833-0.147 |
0.81-4.3 |
22 |
5100 |
MBS1224 |
1200 |
2400 |
36 |
≤25 |
0.833-0.147 |
1.1-4.9 |
30 |
12000 |
MBS1530 |
1500 |
3000 |
29.7 |
≤25 |
0.833-0.147 |
2.4-7.5 |
75 |
15600 |
MBS1830 |
1830 |
3000 |
25.4 |
≤25 |
0.833-0.147 |
4.8-11.6 |
130 |
28000 |
MBS2130 |
2100 |
3000 |
23.7 |
≤25 |
0.833-0.147 |
14-35 |
155 |
34000 |
MBS2136 |
2100 |
3600 |
23.7 |
≤25 |
0.833-0.147 |
19-43 |
180 |
37000 |
MBS2430 |
2400 |
3000 |
21 |
≤50 |
0.833-0.147 |
25-65 |
245 |
54000 |
MBS2736 |
2700 |
3600 |
20.7 |
≤50 |
0.833-0.147 |
32-86 |
400 |
86000 |
MBS2740 |
2700 |
4000 |
20.7 |
≤50 |
0.833-0.147 |
32-92 |
400 |
94000 |
MBS3245 |
3200 |
4500 |
18 |
≤50 |
0.833-0.147 |
64-180 |
800 |
137000 |
...
