2013 Spriral Classifier/ Fine Classifier for Sale
US$ 5,000 - 65,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, spriral classifier
Production Capacity:
95%
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2013 Spriral Classifier MachineryUS$ 5,000 - 700,000MOQ: 1 Set -
Spriral Classifier ,wet Sand ClassifierUS$ 5,000 - 56,000MOQ: 1 Set
-
South America Best Selling Copper and Gold Used Flotation Separating MachineUS$ 3,200 - 78,000MOQ: 1 Set
-
High Gradient High Gradient Magnetic Separator for Concentrating Iron OreUS$ 2,500 - 75,000MOQ: 1 Set
-
Nickel and Cobalt Ore Mining and Dressing Magnetic Separator ---Yufeng BrandUS$ 2,500 - 75,000MOQ: 1 Set
Condition
New
Type
Other, spriral classifier
Production Capacity
95%
Place of Origin
Henan, China
Brand Name
Yufeng
Model Number
FG500/FG1000/2FG1200/2FG1500/FC1200/FC2000/2FC1500/2FC2400
Voltage
380V
Power(W)
3-50
Weight
1980/3005/5310/8000/9800/20500/25700/22100/45800/73000
Certification
ISO&CE
Warranty
2 years(except the easy damaged parts)
After-sales Service Provided
Engineers available to service machinery overseas
This machine is the main equipment in mineral dressing plants, for grading ore pulp size. It is also used for dewatering and other works in sand washing. It’s divided to single spiral and double spirals; according the difference of spiral’s depth in overflow surface, it’s also divided to high weir type and sinking type.
For different types and detailed specifications, please feel free to contact our company. Your any kind inquiry will be highly appreciated.
Main Technical Parameters of Spiral Classifier:
Type |
Model |
Screw Dia (mm) |
Flume Length(mm) |
Spiral Speed(r/min) |
Capacity(t/d) |
Gradient (°) |
Screw Weight(t) |
Power(kw) |
Overall Dimension(mm) |
Weight(kg) |
||
Return Sand |
Overflow |
Driving Motor |
Elevating Motor |
|||||||||
High Weir Classifier |
FG500 |
φ500 |
4500 |
8~12.5 |
135
~210
|
32 |
14-18.5 |
0.75 |
1.5 |
6409×712×1599 |
1980 |
|
FG750 |
φ750 |
5500 |
6.0-10.0 |
340
~570
|
65 |
14-18.5 |
1.1 |
3.0 |
6300×1250×1780 |
3005 |
||
FG-1000 |
φ1000 |
6500 |
5.0~8.0 |
675
~1080
|
110 |
14-18.5 |
1.9 |
7.5 |
7100×1330×2390 |
5310 |
||
FG-1200 |
φ1200 |
6500 |
5.0~8.0 |
1170
~1870
|
155 |
14-18.5 |
3.7 |
7.5 |
0.4 |
7560×1572×2328 |
8000 |
|
FG-1500 |
φ1500 |
8300 |
4.0~6.0 |
1830
~2740
|
235 |
14-18.5 |
5.1 |
11 |
0.4 |
9740×2000×4100 |
9800 |
|
FG-2000 |
φ2000 |
8400 |
3.0~3.5 |
3240
~5400
|
400 |
14-18.5 |
7.1 |
11 |
2.8 |
10000×2570×4468 |
20500 |
|
FG-2400 |
φ2400 |
9200 |
2.5~4.0 |
4650
~7450
|
580 |
14-18.5 |
10.2 |
11-15 |
2.8 |
10800×2980×4700 |
25700 |
|
2FG-1200 |
φ1200 |
6500 |
5.0~8.0 |
2340
~3740
|
310 |
14-18.5 |
3.7×2 |
5.5×2 |
0.4×2 |
8060×3400×3100 |
13300 |
|
2FG-1500 |
φ1500 |
8300 |
4.0~6.0 |
3660
~5480
|
470 |
14-18.5 |
5.1×2 |
7.5×2 |
0.4×2 |
9740×3630×4050 |
22100 |
|
2FG-2000 |
φ2000 |
8400 |
3.0~5.5 |
6480~10800 |
800 |
14-18.5 |
7.1×2 |
11×2 |
2.8×2 |
10000×4600×4470 |
36500 |
|
2FG-2400 |
φ2400 |
9200 |
2.5~4.0 |
9300
-14900
|
1160 |
14-18.5 |
10.2×2 |
15×2 |
2.8×2 |
10800×5400×4700 |
45800 |
|
2FG-3000 |
φ3000 |
12500 |
2.0~3.2 |
14600~23400 |
1785 |
14-18.5 |
20×2 |
18.5×2 |
4×2 |
15600×6640×6350 |
73000 |
|
Submerged Classifier |
FC-1000 |
φ1000 |
7600 |
5.0~8.0 |
675
~1080
|
85 |
14-18.5 |
2.4 |
7.5 |
0.4 |
10000×1680×4000 |
6000 |
FC-1200 |
φ1200 |
8400 |
5.0~8.0 |
1170
~1870
|
120 |
14-18.5 |
4.8 |
7.5 |
0.4 |
10000×1880×4190 |
9280 |
|
FC-1500 |
φ1500 |
10500 |
4.0~6.0 |
1830
~2740
|
185 |
14-18.5 |
6.4 |
11 |
0.8 |
12200×2100×4900 |
12570 |
|
FC-2000 |
φ2000 |
12900 |
3.0~3.5 |
3240
~5940
|
320 |
14-18.5 |
8.6 |
11-15 |
2.8 |
14500×2880×5500 |
29100 |
|
FC-2400 |
φ2400 |
14200 |
2.5~4.0 |
4650
~7450
|
455 |
14-18.5 |
12.8 |
11-18.5 |
4.0 |
15900×3300×6000 |
41000 |
|
2FC-1200 |
φ1200 |
8400 |
5.0~8.0 |
2340
~3740
|
240 |
14-18.5 |
4.8×2 |
7.5×2 |
0.4×2 |
10000×3700×4190 |
19600 |
|
2FC-1500 |
φ1500 |
10500 |
4.0~6.0 |
3660
~5480
|
370 |
14-18.5 |
6.4×2 |
7.5×2 |
0.8×2 |
12200×3840×4850 |
30700 |
|
2FC-2000 |
φ2000 |
12900 |
3.0~5.5 |
6480~11800 |
640 |
14-18.5 |
8.6×2 |
15×2 |
2.8×2 |
14500×4910×5500 |
50000 |
|
2FC-2400 |
φ2400 |
14200 |
2.5~4 |
9300~14900 |
910 |
14-18.5 |
12.8×2 |
18.5×2 |
4×2 |
15900×5730×6000 |
67900 |
|
2FC-3000 |
φ3000 |
14300 |
2.0~3.2 |
14600~23400 |
1410 |
14-18.5 |
24.1×2 |
22×2 |
4×2 |
17700×7000×8000 |
84900 |
|
....
