Specifications
fiber cement board production lineboard dimenstion: 2400*1200*5-20mm
operator needed: 40 persons
capacity:3 millions sqm/y
Fiber cement board production line
1. Product physical properties
The main technical performance index comply with ≤ fiber reinforced calcium silicate board ≥ Jc/T564-2008
Name |
D0.8 |
D1.1 |
D1.3 |
D1.5 |
Density (g/cm3) |
≤0.95 |
0.95<D≤1.20 |
1.20<D≤1.40 |
>1.40 |
Thermal conductivityW/(m.k) |
≤0.20 |
≤0.25 |
≤0.30 |
≤0.35 |
water content |
≤10% |
|||
Moisture expansivity |
≤0.25% |
|||
Thermal shrink ratio |
≤0.50% |
|||
non-combustibility |
GB8624-2006 A-class |
|||
watertightness |
After tested for 24 hour,the back face of board can have wetness trace,no drip. |
|||
Freeze-thaw durability |
After freeze-thaw cycle for 25 times,there is no rupture and layer
|
|||
2. Main raw material
Silicon materials: quartz powder and fly ash, diatomite, etc
Calcium materials:lime powder, cement, calcium carbide mud, etc
Fiber materials: wood paper textile fiber, cotton fiber, wollastonite, etc
Unit square meters materials consumption table (in 6 mm thick basis)
Paper fiber |
0.4Kg/m2 |
wollastonite |
0.67 Kg/m2 |
lime powder |
0.4 Kg/m2 |
cement |
1Kg/m2 |
quartz powder |
3.35 Kg/m2 |
