Specifications
Portable Belt Conveyor:1.480t/h conveying capacity;
2.Simple structure,convenient maintenance;
3.ISO,CE,SGS approved.
Coal Mine rubber belt conveyor for Africa market
Brief Introduction of Belt Conveyor:
It mainly consists of frame rack, belt, roller, tensioner, transmission part. The frame rack is made of steel, and the belt is made of cotton or nylon as the core. It has the advantages of big conveying capacity, simple structure ,convenient repair and standard parts.
Features of Belt Conveyor:
1.Large conveying capacity.
2.Noise reduction.
3.Simple structure.
4.Easy maintenance.
5.Energy-saving and low cost.
(The following points should be pay attention to: Belt Conveyors can be operated in the circumstance temperature range from -20°C to +40°C. The temperature of transferred material by Belt Conveyors should be lower than 50°C.)
Application of Belt Conveyor:
It is widely used in industries such as mine, metallurgy and coal to convey loose materials and finished products.
Types of Belt Conveyor:
We have various types of belt conveyor, such as 400, 500, 650, 800, 1000, 1200 etc.
Technical Parameters of Belt Conveyor:
Belt width(mm) |
Conveying length(m)
Power(kw)
|
Conveying |
Conveying |
||
500 |
<=12 3 |
12-20 4-5.5 |
20-30 5.5-7.5 |
1.3-1.6 |
78-191 |
650 |
<=12 4 |
12-20 5.5 |
20-30 7.5-11 |
1.3-1.6 |
131-323 |
800 |
<=6 4 |
6-15 5.5 |
15-30 7.5-15 |
1.3-1.6 |
278-546 |
1000 |
<=10 5.5 |
10-20 7.5-11 |
20-40 11-22 |
1.3-2.0 |
435-853 |
1200 |
<=10 7.5 |
10-20 11 |
20-40 15-30 |
1.3-2.0 |
655-1284 |
Main pictures of Belt Conveyor
Our company information:
Our Certification of water air cooler
Service is important in choosing a good wood pellet machine supplier
2. visit to our factory and have an investigation and performance test
3. engineers avialable to service machinery overseas.
4. warranty 1 year,quality gurantee, except wear parts and wrong operation
To know more, pls contact Monica Li.Cell:0086-13869210828
Skype:kattyli1988
