Specifications
304 Stainless Corrugated Packing:1.304 stainless material,high efficiency
2.Low pressure drop
3.Low price, good quality
304 Stainless Corrugated Packing Advantage:
1. High efficiency, low pressure drop
2.ISO9001:2008 Approved
3.big flux
3. 304 Stainless material ,anti Corrosion resistance
304 Stainless Corrugated Packing introduction and Application
It is formed from vertical sheets of corrugated metal with the angle of the corrugation reversed in adjacent sheets to form an open structure with inclined flow channel. Its structure can not only change the distribution of liquid, but also increase the transfer efficiency. It is recognized worldwide as the leader in application with low liquid-loading systems or temperature-sensitive compounds,
Application: Vacuum distillations, specialty chemicals, and many highly refined, value-added processing operations also benefit from gauze packing and efficiency improving capabilities. It is also the most efficient commercial tower packing available on the market.
304 Stainless Corrugated Packing Technical data
Model |
Wave height mm |
Surface area m²/m³ |
Theoretical plate I/m |
Void volume % |
Pressure drop MPa/m |
F factor M/s(kg/m3)0.5 |
SM125 |
24 |
125 |
1-1.2 |
98.5 |
1.5*10-4 |
3 |
SM250 |
12 |
250 |
2-3 |
97 |
1.52*10-4 |
2.6 |
SM350 |
8 |
350 |
3.5-4 |
95 |
1.5*10-4 |
2 |
SM450 |
6.5 |
450 |
4-4.5 |
93 |
1.8*10-4 |
1.5 |
