Home > Industrial Equipment & Components > Environment Protection Device > Waste Treatment Equipment > Metallic Intalox Saddles

Metallic Intalox Saddles

Name: Metallic Intalox Saddles
Brand: ZHONGYING
SKU: 138694845

Negotiable MOQ: 1 Cubic Meter (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Jiangxi, China

Brand Name:

ZHONGYING

Contact Supplier Request Quote Chat Now

Pingxiang Zhongying Packing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai shenzhen and any port in China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangxi, China

Brand Name ZHONGYING

Specifications

1. 20 years professional manufacturer of Metal intalox saddle
2. Material:SS304 304L 316 316L 410

Metal intalox saddle is made of materials like carbon steel, stainless steel or Aluminum alloy, etc. The product has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on. It is especially suitable for rectification towers under vacuum to treat thermosensitive, decomposable, polymerizable or cokable systems, so it is widely used in packing towers in petrochemical industry, chemical fertilizer industry and environmental protection, etc..

Technical data

Size mm	Thickness (mm)	Bulk density kg/m³	Number (per m³)	Free volume %	Surface Area (m²/m³)	Packing Factor (m^-1)
15	0.25	280	347000	96.5	305	167
25	0.3	255	135000	96.8	241	135
40	0.4	231	50200	97.1	161	79
50	0.4	149	15000	98.1	104	59
60	0.4	142	8400	98.2	85	50
70	0.5	113	4600	98.6	62	39

The above data is reference to material stainless steel (AISI304) in the material thickness shown.

Material available:

carbon steel, stainless steel including 304, 304L, 410,316, 316L.

Advantage

1) A versatile packing used in distillation, absorption and other operations.

2) Used in both deep vacuum and high pressure towers.

3) ZHONGYING metal saddle is high performance random packing successfully used in mass transfer towers both small and large diameter. It is frequently used in deep vacuum towers where low pressure drop is crucial and also high pressure towers where capacity significantly exceeds conventional trays.
