High Surface Area K5 bio media with 52 cells
| Product Show |
1.Description of product
| Product | Water tremant media, Mbbr Suspending bio media, PE bio media,Aquarium bio media, PE bio film , biological active filler,K5 bio media, K1 media, K3 media |
| Application | Water treatment, Aquarium ,Fish Farm |
| Size | 10*7mm, 11*7mm, 12*9mm, 14.5*9.8mm, 25*12mm, 25*8mm |
| Production Capacity | More than five cubic meters per each day |
| Material | 100% Virgin , Safe, Enviromental HDPE material |
| Sample | Free sample |
| Mainly Market | United States, Germany , Australia, Saudi Arabi, United Kingdom |
| Accepted Payment Method | T/T. L/C. Paypal, Western Union |
What's the difference from 25*12mm mbbr bio media?
1. Cells
25*12mm, only have 19 cells , and for K5 bio media, we make the hole as bigger as better. It has 52 cells .
2. Surface Area
Compare with K3 bio media of 25*12mm. The surface area is around >500m2/m3, but for K10 bio media of 25*7
size, the surface area is bigger than >850m2/m3
3. Delivery
Advanced Equiment, delivery fastly. Ensure with the delivery time
4. Quality
We use 100% virgin Enviromental safe HDPE material, no pollution .
5. Shape:
Our Shape is perfect round , Smooth surface,
Operation Progress:
Water Treatment Media introduction:
MBBR media is a new kind of suspension carriers. It modified polymeric material with the promoted additions of bio-enzyme, it improves the enzymatic catalysis, so it possess excellences of larger specific surface, being easy to multiply biofilm, unease to fall off, high denitrification, good hydrophile, high biological activity and so on.
Process Principal:
The waste water go through the suspending media of MBBR reactor, form the biological membrane on the surface of the media gradually, with the action of the microbial on the biological membrane, the waste water is purified. The media can move freely in the reactor with the mixing of the water; For the aerobic reactor, the aeration will make the media move; For the anaerobic reactor, mechanic mixing will make the media move. Our MBBR media is new-developed media for the MBBR process, has better treatment effect compare to traditional media.
Advantages of Bio Filter Media:
1) High relative surface area
2) Lightweight zero buoyancy
3) Self cleaning
4) Ideal surface for bio filter to multiply
Ideal Applications:
1) Sewage treatment
2) Aquaculture farms
3) Koi Filter Media
Technical Characteristics of PE10 Biological Active filter media with 52 cells :
PRODUCT NO |
PE01 |
PE02 |
PE03 |
PE04 |
PE05 |
|
Diameter× Height(mm) |
12×9 |
11×7 |
10×7 |
14.5×9.8 |
25×12 |
Weight per m3(kg) |
120 |
140 |
150 |
120 |
95 |
Number of unites per m3 |
666,340 |
1038,000 |
1038,700 |
341,000 |
135,000 |
Specific surface area(m2/m3) |
>800 |
>900 |
>1000 |
>800 |
>500 |
|
Nitrification Efficiency |
650 |
750 |
850 |
650 |
400 |
Color |
Natural White |
||||
Material |
Virgin polythene (PE) |
||||
|
Bio-film formation duration (days) |
5-15
|
||||
|
Preferential Temperature (°C) |
<65 |
||||
|
Service Life (year) |
≥10 |
||||
Package Information
| 1*20GP | 1*40GP | 1*40HQ | |
| PackageQ"ty | 27 m3 of plastic bags. 25m3/Carton | 57 m3 of plastic bags. 25m3/Carton | 67 m3 of plastic bags. 25m3/Carton |
| Delivery time | within 15 working days | within 55 working days | within 65 working days |
2. Pictures of the product
Other MBBR bio media Size:
| Company Show |
1. About us
2. Why Choose us
ü Complete production line, quick delivery
ü Advanced equipments, good quality
ü Professional skills, all-related services
3. Certifications
4. Our Markets
| Main Markets | 20.00% North America |
| 20.00% South America | |
| 15.00% Eastern Europe | |
| 10.00% Southeast Asia | |
| 10.00% Africa | |
| 5.00% Oceania | |
| 5.00% Northern Europe | |
| 5.00% Southern Europe | |
| Total Annual Sales Volume | US$2.5 Million - US$5 Million |
| Export Percentage | 51% - 60% |
5. General Questions
1.a. Are you Trading Company or Factory:
b. We have more than 20 experience year production in this line .
2.a. What's your production ability for one month?
b. We can product 2000 cubic meters for one month .
3.a. What's your MOQ?
b. 1 Cubic meter is available .
4.a. What's your shipping port?
b. Shenzhen, Shanghai ,China
5.a. What's your Payment Terms?
b, Generally Speaking. 50% T/T in advance, 50% T/T after got the copy of B/L
6. Contact
Try order is acceptable. Sample is available.
Welcome to inquire, we will feedback within 24 hours.
