Plastic honeycomb packing,PP inclined tube packing

Specifications

1)20 years professional manufacture
2)PP inclined tube packing
3)Ontime delivery
4)One-stop service
5)ISO9001:2000

PP honeycomb Packing maily  used for sediment and degritting,  It applys  to construction sand, general industrial and in addition to drinking water, sewage precipitation, precipitation every oil and tail concentrate processing, which is suitable for newly-built project, and also applies to the transformation of the existing old pool. All can obtain good economic benefit.





Plastic Straight Packing i.s mainly used for the bio-filter high load bio-filter, tower bio-filter, submerged type bio-filter (also called contact oxidation pool) and biological somewhere in the microbial carriers, and the industrial organic wastewater biochemical treatment of sewage and city.









PP honeycomb Packing

Features :





1, large watted perimeter, small hydraulic radius.



2,good laminar flow, particles falling free from flocculent flow interference.



3,as long as inclined tube is 1meter, effective loadis designed  by 3-5 tons/m ² .VO in 2.5-3.0 mm/sec range and best water quality.



4, adopting  honeycomb inclined pipe in water inlet with tube 2.0 to 3.0 meters ensure safe operation processing in high turbidity of 50-100 kg/m3 clay sand content.



5, processing power of inclined pipe sedimentation tank is horizontal-flow settling tank 3-5 times, accelerating water clarification and pulse water clarification of 2-3 times.





  PP inclined tube packing







PP honeycomb Packing

Technical date:



Specification(Diam)	Thickness m/m	sheet /m2	weight	m3/mt	specific surface area n2/m3
30mm	0.4	68	32	31.25	116
	0.45	68	36	27.7	116
	0.50	68	40	25	116
35mm	0.40	56	26	38.5	109
	0.45	56	29	34.5	109
	0.50	56	32.5	30.7	109
50mm	0.45	40	21	47.6	97
	0.50	40	23	43.5	97
	0.55	40	25.5	39.2	97
60mm	0.55	33	21	47.6	75
	0.60	33	23	43.5	75
	0.65	33	25	40	75
80mm	0.70	25	22	47.6	50
	0.80	25	25	43.5	50
	0.85	25	27	40	50



Porduct pictures:











Structure picture:



:

 Welcome to inquriy!
