High Abrasion Ball Mill Ling Brick
US$ 0.89 - 1.49
MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
Zhongying
Model Number:
As you require
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Exported 70% Alumina Lining Brick-Low PriceUS$ 0.645 - 1.49MOQ: 1000 Pieces -
Industrial Acid Proof PlateUS$ 0.295 - 0.659MOQ: 500 Pieces
-
Acid Resistant BrickUS$ 0.295 - 0.659MOQ: 500 Pieces
-
New Hot -- 95 % Alumina Lining Ball Mill BrickUS$ 0.645 - 1.49MOQ: 1000 Pieces
-
Acid Proof Ceramic Tiles.ceramic Tile for Acid&alkali PlantUS$ 0.31 - 0.76MOQ: 1000 Pieces
Place of Origin
Jiangxi, China
Brand Name
Zhongying
Model Number
As you require
Specifications
1.Size can be ordered, Regular and irregular ceramic brick2.Available alumina content: 92%-95%
3.High quality, High densit
Alumina Ceramic Lining Brick available alumina content: 70%, 80%.92%, 95%
Alumina Ceramic Brick Application ::
Alumina ceramic lining bricks used as liner of ball mill, It can be used for ball mill, mixing mill, vibration mill, sand mill, etc. The products are widely used in construction ceramics, sanitary ceramics, kaolins, refractory materials, paints, coatings and other fields.
92% Alumina Ceramic Brick Advantage:
have characteristics of high strength, high density, high abrasion, entire specification, strong practicability.
Alumina Cramic Brick technical Data:
| Performance Index | 70 Series | 80 Series | Series | 95 Series |
| Al2O3(%) | ≥67 | ≥80 | ≥92 | ≥95 |
| Fe2O3(%) | ≤1.5 | ≤0.5 | ≤0.25 | ≤0.2 |
| Mohs Hardness | 9 | 9 | 9 | 9 |
| Water Absorption Rate(%) | ≤0.02 | ≤0.02 | ≤0.02 | ≤0.02 |
| Bulk Density(g/cm3) | ≥3.0 | ≥3.2 | ≥3.60 | ≥3.65 |
| Wearing Lost(‰) | ≤0.2 | ≤0.2 | ≤0.15 | ≤0.10 |
| Color | Yellow | White | White | White |
| Material | Bauxite | Alumina Powder | Alumina Powder | Alumina Powder |
Available size of Lining Brick
| Name | Length (mm) | Width 1 (mm) | Width 2 (mm) | Thickness(mm) | |
| 40~90mm Thickness Lining Brick | Rectangle Brick | 150±2 | 50±1 | 50±1 | 40/50/60/70/77/90±1 |
| Trapezoid Brick | 150±2 | 50±1 | 45±1 | 40/50/60/70/77/90±1 | |
| Half Rectangle Brick | 75±1 | 50±1 | 50±1 | 40/50/60/70/77/90±1 | |
| Half Trapezoid Brick | 75±1 | 50±1 | 45±1 | 40/50/60/70/77/90±1 | |
| Flake Brick | 150±2 | 25±1 | 22.5±1 | 40/50/60/70/77/90±1 | |
| Special Specification Lining Bricks | 80x50x55 | 55±2 | 50±1 | 50±1 | 80±1 |
| 110mm Ling Brick | 75±1 | 45±1 | 41±1 | 110±2 | |
| 110mm Half Ling Brick | 37.5±1 | 45±1 | 41±1 | 110±2 | |
| Brick for Manhole and Drainhole | The specification can make according to the customers' requirements. | ||||
We also can design Speical size as u need
