92% Ceramic Alumina Lining Brick in Ball Mill
US$ 0.89 - 1.49
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Type:
Ceramic Plates
Application:
Industrial Ceramic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Acid Resisant Brick&Plate--High QualityUS$ 0.295 - 0.659MOQ: 500 Pieces -
Porcelain Plates With Acid&AlkaliUS$ 0.29 - 0.65MOQ: 1000 Pieces
-
Acid Proof Bricks,technical Ceramic Tile,micro Porous Ceramic Filter Media,ceramic BricksUS$ 360 - 450MOQ: 1 Metric Ton
-
Refractory Bricks,catalyst Supporter,20~75% Alumina ContentUS$ 0.5 - 3.5MOQ: 1 Metric Ton
-
150*150mm Acid Resistant Brick(Good Price)US$ 0.31 - 0.76MOQ: 1000 Pieces
Place of Origin
Jiangxi, China
Type
Ceramic Plates
Application
Industrial Ceramic
Material
Alumina Ceramic
Model Number
As u need
Brand Name
Zhongying
Specifications
1. Long service life, high abrasion2.High quality, delivery fastly, Competitive price
3.Strong paraticability,ISO9001:2008
Burning in Kin:
Alumina Lining Brick Package:
Alumina Ceramic Lining Brick available alumina content: 70%, 80%.92%, 95%
Alumina Ceramic Brick Application ::
Alumina ceramic lining bricks used as liner of ball mill, It can be used for ball mill, mixing mill, vibration mill, sand mill, etc. The products are widely used in construction ceramics, sanitary ceramics, kaolins, refractory materials, paints, coatings and other fields.
92% Alumina Ceramic Brick Advantage:
have characteristics of high strength, high density, high abrasion, entire specification, strong practicability.
Alumina Cramic Brick technical Data:
| Performance Index | 70 Series | 80 Series | Series | 95 Series |
| Al2O3(%) | ≥67 | ≥80 | ≥92 | ≥95 |
| Fe2O3(%) | ≤1.5 | ≤0.5 | ≤0.25 | ≤0.2 |
| Mohs Hardness | 9 | 9 | 9 | 9 |
| Water Absorption Rate(%) | ≤0.02 | ≤0.02 | ≤0.02 | ≤0.02 |
| Bulk Density(g/cm3) | ≥3.0 | ≥3.2 | ≥3.60 | ≥3.65 |
| Wearing Lost(‰) | ≤0.2 | ≤0.2 | ≤0.15 | ≤0.10 |
| Color | Yellow | White | White | White |
| Material | Bauxite | Alumina Powder | Alumina Powder | Alumina Powder |
Available size of Lining Brick
| Name | Length (mm) | Width 1 (mm) | Width 2 (mm) | Thickness(mm) | |
| 40~90mm Thickness Lining Brick | Rectangle Brick | 150±2 | 50±1 | 50±1 | 40/50/60/70/77/90±1 |
| Trapezoid Brick | 150±2 | 50±1 | 45±1 | 40/50/60/70/77/90±1 | |
| Half Rectangle Brick | 75±1 | 50±1 | 50±1 | 40/50/60/70/77/90±1 | |
| Half Trapezoid Brick | 75±1 | 50±1 | 45±1 | 40/50/60/70/77/90±1 | |
| Flake Brick | 150±2 | 25±1 | 22.5±1 | 40/50/60/70/77/90±1 | |
| Special Specification Lining Bricks | 80x50x55 | 55±2 | 50±1 | 50±1 | 80±1 |
| 110mm Ling Brick | 75±1 | 45±1 | 41±1 | 110±2 | |
| 110mm Half Ling Brick | 37.5±1 | 45±1 | 41±1 | 110±2 | |
| Brick for Manhole and Drainhole | The specification can make according to the customers' requirements. | ||||
We also can design Speical size as u need
