Grinding Ball Mill/ball Mill
US$ 500 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Ball Mill, Heading Machine
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cooler/rotary Cooler/LQ Rotary CoolerUS$ 500 - 100,000MOQ: 1 Set -
Fertilizer/fertilizer Machinery/fertilizer EquipmentUS$ 500 - 100,000MOQ: 200000 Tons
-
Tube MillUS$ 500 - 100,000MOQ: 1 Set
-
Granulator/PTF Model Spray Rotary Drier-GranulatorUS$ 50 - 100,000MOQ: 1 Set
-
Cement Machinery/rotary Kiln/cement KilnUS$ 500 - 100,000MOQ: 1 Set
Condition
New
Type
Other, Ball Mill, Heading Machine
Place of Origin
Jiangsu, China
Brand Name
right
Model Number
s-329
Specifications
grinding ball mill/ball mill is the key equipment for grinding after the crush process, it is widely used in cement ,silicagrinding ball mill/ball mill
Ball Mill/ grinding mill/crusher is an efficient tool for grinding many materials into fine powder. The ball mill is used to grind many kinds of mine and other materials, or to selectthe mine. It is widely used in building material, chemical industry, etc. Thereare two ways of grinding: the dry process and the wet process. It can be dividedinto tabular type and flowing type according to different forms of discharging material.
Technical Data:
Technical Data:
| Specification(mm) | Production Capacity(t/h) | Effective Volume(t/h) | Power(kw) | Remarks. | Effective Size(mm) | ||
| Ø900×3200 | 0.6-0.8 | 2 | 30 | steel liner | <25 | ||
| Ø1200×4500 | 1.8-2.2 | 4.43 | 55 | steel liner | <25 | ||
| Ø1500×5700 | 4.5-5.0 | 8.75 | 130 | steel liner | <25 | ||
| Ø1830×6400 | 7.0-9.0 | 14.76 | 210 | steel liner dry | <25 | ||
| Ø1830×6400 | 7.0-9.0 | 14.76 | 210 | rubber liner wet | <25 | ||
| Ø1830×7000 | 7.0-12.5 | 16.44 | 245 | steel liner dry | <25 | ||
| Ø2200×6500 | 14-15 | 21.3 | 380 | steel liner with 380V motor | <25 | ||
| Ø2200×6500 | 14-15 | 21.3 | 380 | steel liner with 600V motor | <25 | ||
| Ø2200×7000 | 15-16 | 23.1 | 380 | steel liner with 380 motor | <25 | ||
| Ø2200×7000 | 15-16 | 23.1 | 380 | steel liner with 6000V motor | <25 | ||
| Ø2200×7000 | 15-16 | 23.1 | 380 | ruber liner with 10000V motor | <25 | ||
| Ø2400×8000 | 18-10/16-17 | 32.2 | 475 | steel liner with 6000V motor | <25 | ||
| Ø2400×10000 | 18-22/17-19 | 40.3 | 630 | ZD80 with 10000V motor | <20 | ||
| Ø2400×12000 | 25-27/20-23 | 46.5 | 800 | MBY630 with 10000V motor | <25 | ||
| Ø2600×13000 | 30-32/26-28 | 60.5 | 1000 | MBY710 with 10000V motor | <25 | ||
| Ø3000×9000 | 35-40/28-32 | 58.5 | 1000 | MBY710 with 10000V motor | <25 | ||
| Ø3000×11000 | 40-44/33-35 | 71 | 1250 | MBY800 with 10000V motor | <20 | ||
| Ø3000×12000 | 43-46/36-38 | 73.9 | 1400 | MBY800 with 10000V motor | <20 | ||
| Ø3000×13000 | 45-48/38-40 | 76.8 | 1400 | MBT900 with 10000V motor | <20 | ||
| Ø3200×13000 | 50-53/42-44 | 88.95 | 1600 | MBT1100 with 10000V motor | <20 | ||
| Ø3800×13000 | 65-75 | 133.86 | 2000 | JS130-C-F1 with 10000V motor | <25 |
