High capacity sawdust dryer machine for sale
Sawdust dryer machine ( QHG219 ) is a kind of dryer enquipment used in animal feed and industry. It is also called pulse air flow drier or hot air pipeline drier with the advantages of direct heating, fast drying, foldable installation and saving space.
Sawdust dryer machine continuously conveys materials into drying tubes by screw conveyor, which are affected by high-speed heat air and disperse in drying tubes. Simultaneously, the water from raw materials is separated by the separator. Finally processed materials come into powdery and granulous finished products.
QHG series
1. Features & Advantages
1) Operated under negative pressure condition, it doesn’t cause pollution and keeps environment tidy.
2) The consumption of the electricity and fuel of airflow drier were lower than other drying equipments.
3) The whole drying process only takes 1-5s and raw materials’ temperature is not higher than 50C.
4) QHG dryers have a lot of advantages of direct heating, fast drying, foldable installation and saving space.
5) The airflow speed fluctuates through the variable diameter pipeline which greatly improves the heat transfer coefficient and greatly saves energy in continuous drying operation.
2. Technical parameter
|
|
Model |
Power (kw) |
Capacity(t/h) | Dimension(m) | Weight(t) | Note |
| QHG219x4 | 4 | 0.3-0.4 evaporation 0.2 | 4*2*2 | 0.85 | Include two pulses,one drying drum,one Φ800,cyclone,hot blast stove is contained | |
| QHG273X4 | 4 | 0.4-0.7evaporation 0.25 | 5*2.5*2 | 1.1 | ||
| QHG315x4 | 5.5 | 0.5-1 evaporation 0.3 | 5*3*2.5 |
1.4 |
3. Working Principls
Its principle is to let damp raw materials and high temperature gas mixing and finally separated the water from raw materials through the separator.
4. Product Application
Airflow dryers can dry many kinds of raw materials with high moisture in the field of building materials, metallurgy, chemical industry, cement, sand, chalk slag, slags, coal powder, mining ore powder, clay, limestone, wood chips and wood powder, animal dung and so on. The airflow dryer has a better adaptability and can dry a variety of materials with a simple and reliable operation.
5. Auxiliary enquipments
Sawdust dryer machine can work together with cyclone in the feed processing factory.
6. Production Certificates
Pellet mills, hammer mills and mixers produced by Shandong Double Crane Machinery Manufacturer Co., Ltd. are mostly certified by CE, ISO and SGS.
Double Crane are able to choose a more adapted packing ways for you such as wooden case and iron case. Pls kindly tell us your idea, we will immediately design a better project with reasonable shipping charges and reliable packing to suit to your requirements.
a. Technical support online service provided.
b. Technical files service provided.
c. On-site training service provided.
d. Spare parts replacement and repair service provided.
Shandong Double Crane Mchinery Manufacturer Co., Ltd. was established in 2005. And the factory is located in Leling city, Shandong province and occupies over 60,000 square meters. There are more than 150 workers, 30 mechanical designers and experts and 3 sales team.
Adhering to the concept of green, eco-friendly environment and humanisum, by learning domestic and foreigh advancedd technology, we are dedicated to R&D, production and sale of feed machines, biomass energy machines nd organic fertilizer machines. Among them, hammer mills and feed pellet machine are both certified by SGS, CE and ISO 9001. Upon to now, our products have been already exported into more than 30 countries and regions in the world. They have been enjoyed a high reputation by clients with high quality, reliable service and nice performance.
Our factory and business are rapidly expanding in 2015. We sincerely hope to establish a new cooperative relationship with clients in the world. If you are such a client and interested in feed machines, pls don't hesitate and contact us soon. We will repay you best products and best service.
1. Q: Are you a trading company or a manufacturer?
A: We are a manufacturer, which has almost 10 years of experience in this industry and be able to offer you the best price.
2. Q: How can I get to your company?
A: You can get a flight to Jinan Airport. We are just about 1 hours away from Jinan Airport.
3. Q: How long is your warranty period?
A: One Year (Calculated from the equipment arrives the customer’s side.).
4. Q: Will you send engineers to install the plant?
A: yes, but at an extra cost payable by the customer. Or you can get local contractors to do the commissioning and we send one supervising engineer.
5. Q: Have you sold your products to Europe?
A: Yes, We have designed and installed more than 1000 turnkey pellet lines. Many of our customers are from Europe, including Latvia, France, Greece, Romania, Lithuania, etc.
1. Which kinds of machines could you want?
2. What are you going to use this machine for?
3. What's the voltage and output of machines do you prefer?
