Help CenterMade in China Hydraulic Cylinder Clevis Mount
Related Products
Specifications
Hydraulic Cylinder Clevis MountOEM Customised Service Hydraulic Cylinder Clevis Rod End
45C Steel
Made in China
ISO9001
Product: Hydraulic Cylinder Clevis Mount
1. Clevis End Mounting
2. 2320 PSI Working Pressure, 3" Bore, 70" -72.5" Stroke, 1" Rod Diameter
3. Black, Single Acting Application
Intended Use:
It is mainly used in the hydraulic system for various engineering machinery, lifting machinery, transport machinery, ship machinery, metallurgical and mining machinery and engineering vehicles.
Service and Quality Assurance:
We offer OEM service too, welcome any of drawing from you. We also have design Dept and strict QC Dept who can control the quality in steady.
If you have any questions, please feel free to contact with our office for more details.
Order Instruction:
* Customer can select cylinder model and bore according to the load size and mounting mode.
* The stroke can be selected from the range in the table at your choice.
| PARAMETER | |||||||
| Max.Cylinder Bore | 280mm | ||||||
| Min.Cylinder Bore | 10mm | ||||||
| Max.Piston Rod Dia. | 280mm | ||||||
| Min.Piston Rod Dia. | 10mm | ||||||
| Max.Retract Length | 3500mm | ||||||
| Min.Retract Length | 50mm | ||||||
| Max.Stretch Length | Single stage cylinder 6500mm | ||||||
| Dual stage cylinder 12500mm | |||||||
| Min.Stretch Length | 60mm | ||||||
| Max.Working Pressure | 4500PSI | ||||||
| Min.Working Pressure | 1000PSI | ||||||
| Working Pressure of Heavy-duty Cylinder | 7500PSI | ||||||
