Specifications
Shock Absorber Piston RodForged, Hard Chrome Plated, Hydraulic Cylinder Rod, Hardened Induction with Heat Treatment
ISO9001
Chrome Plated Hydraulic Cylinder Piston Rod
Name |
Technical parameters |
Remarks |
Diameter |
Φ9-Φ200 |
|
Diameter tolerance |
F6-f9 |
Customized |
Thickness of chromium coating (μm) |
Δ=0.015-0.05 |
Customized |
Surface roughness |
Ra0.2-Ra0.4 |
|
Cylindricity (mm) |
≤0.01 |
|
Straightness (mm) |
≤0.15/1000 |
|
Surface hardness |
HB220-HB260 |
|
Neutral salt spray test (NSS) |
Class 9,120h |
Refer to GB6458-86 standard, equivalent to ISO3768-1976 |
Name |
Technical parameter |
Remarks |
Length |
100mm - 6 meter |
|
The thickness of Induction quenching hard layer (mm) |
δ≥0.1 |
Customized |
Thickness of hardening layer |
Re68-72 |
|
Material commonly used reference tables:
Common material |
GB |
ISO |
UNI |
45 |
C45 |
|
|
20MnV6 |
|
|
|
38MnV6 |
|
|
|
38CrMoAl |
|
42CD4 |
|
20Cr |
|
|
|
AISI304 |
|
|
Hydraulic Cylinder Piston Rod Workshop
In a piston engine, a piston rod joins a piston to a connecting rod.
Many internal combustion engines, and in particular all current automobile engines, do not have true piston rods, and the term piston rod is often used as asynonym for connecting rod in the context of these engines.
All engines with crossheads do have true piston rods. These include most steam locomotives and large marine diesel engines.
barras de cilindro hidráulico de pistón, surtidor de China, Chrome Revestimiento, tratamiento térmico, Fábrica OEM, idrauliche canne cilindro del pistone, fornitore della Cina, Chrome Coating, trattamento termico, OEM di fabbrica, vökva strokka stangir stimpla, Kína Birgir, Króm Húðun, hitameðferð, OEM Factory, Hydraulikzylinder Kolbenstangen, China Lieferant, Chrom-Beschichtung, Wärmebehandlung, OEM-Fabrik, tiges hydrauliques piston-cylindre, fournisseur de la Chine, revêtement en chrome, traitement thermique, usine OEM, hastes de cilindro hidráulico do pistão, China Fornecedor, Chrome revestimento, tratamento térmico, OEM da fábrica, hydraulcylinder kolvstänger, Kina Leverantör, krombeläggning, värmebehandling, OEM fabrik, hydraulische cilinder zuigerstangen, China Leverancier, Chroom Coating, Warmtebehandeling, OEM Factory,
vástago del pistón del cilindro hidráulico , haste de pistão do cilindro hidráulico , idraulica steli di cilindri pneumatici , Hydraulikzylinder Kolbenstange , la tige de piston du vérin hydraulique , vökva strokka stimpilstöng , hydraulisk cylinder stempelstang , hydraulcylinder kolvstång , hydraulische cilinder zuigerstang , hidraulika cilindro vástago
