Mobile Truck Cranes XCMG QY25K-II Spare Parts

Mobile Truck Cranes XCMG QY25K-II Spare Parts thumbnail-1
Mobile Truck Cranes XCMG QY25K-II Spare Parts photo-1
US$ 10,000 - 300,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
all
Rated Loading Capacity:
26400KG
Contact Supplier Request Quote Chat Now
Tianjin Votai Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application all
Rated Loading Capacity 26400KG
Rated Lifting Moment Base boom:948KN.m
Max. Lifting Load 25T
Max. Lifting Height Fully extended boomv and Jib: more 40.8m
Span Lateral: 6m
Place of Origin Jiangsu, China
Brand Name XCMG
Model Number QY25K

Specifications

Truck Cranes:
One stop service
Competitive prices
Comprehensive after-sale services and spare parts



Truck Crane:

By the upgrade of lifting arm technology optimization, Xuzhou Heavy Machinery establishes the leading position in the key technologies of oblong section lifting arm and flexible lifting arm system automatically controlled by single cylinder mutually locked......



Classificatory Item Unit Parameter
Outline dimension Overall length mm 12360
Overall width mm ≤2500
Overall height mm 3380
Wheel base Axle 1, Axle 2 mm 4125
Axle 2, Axle 3 mm 1350
Mass Total mass in travel state kg 26400
Axle load Axle 1 kg 6100
Axle 2, Axle 3 kg 21800
Travel performance Travel speed Max. travel speed km/h 72
Min. stable travel speed km/h 3
Turning diameter Min. turning diameter m 22
Min. turning diameter at boom tip m 24
Min. ground clearance mm 260
Approach angle (°) 16
Departure angle (°) 13
Braking distance (at 30km/h with full load) m 10
Max. grade-ability % 27
Fuel consumption for 100km L 35
Power Model   D6114ZLQ5B
Engine rated output kW/(r/min.) 158/2200
Engine rated torque N.m/(r/min.) 790/1400
Engine rated speed rpm. 2200

Main Technical Data for Lifting Operation

Classificatory Item Unit Parameter
Lifting performance Max. total rated lifting capacity t 25
Min. rated working radius m 3
Turning radius at turntable tail m ≤3.065
Max. load moment Base boom kN.m 948
Fully extended boom kN.m 521
Fully extended boom + Jib kN.m 331
Outrigger span Longitudinal m 4.8
Lateral m 6
Lifting height Base boom m 10.5
Fully extended boom m 32.5
Fully extended boom + Jib m 40.8
Working speed Boom raising time s 75
Boom full extension time s 100
Max. swing speed r/min 2.5
Hoist speed Main winch Full load m/min ≥70
No load m/min ≥100
Aux. winch Full load m/min ≥60
No load m/min ≥100
