Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Compactor > LTS 212H and LTS 214H Single Drum Electric Start Hydraulic Vibratory New Road Roller

LTS 212H and LTS 214H Single Drum Electric Start Hydraulic Vibratory New Road Roller

LTS 212H and LTS 214H Single Drum Electric Start Hydraulic Vibratory New Road Roller thumbnail-1
LTS 212H and LTS 214H Single Drum Electric Start Hydraulic Vibratory New Road Roller thumbnail-2
LTS 212H and LTS 214H Single Drum Electric Start Hydraulic Vibratory New Road Roller photo-1
LTS 212H and LTS 214H Single Drum Electric Start Hydraulic Vibratory New Road Roller photo-2
US$ 34,000 - 40,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Single Drum Roller
Travel Speed:
12Km/H, 11Km/H
Contact Supplier Request Quote Chat Now
Henan Light Industrial Products Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Single Drum Roller
Travel Speed 12Km/H, 11Km/H
Grade Ability 30%
Brand Name OEM
Model Number LTS 212H, LTS 214H
Power(W) 110 KW
Dimension(L*W*H) 5860*2280*3020MM, 5820*2278*3050MM
Weight 14000KG, 12000KG
Certification QS, CE
After-sales Service Provided Engineers available to service machinery overseas

LTS 212H and LTS 214H single drum electric start hydraulic vibratory new road roller

Product Description





Standard configuration



Model Engine Travelling system Vibrating system cab
LTS212H
LTS214H 		cummins 6BT5.9 adopt the products of  SAUER or REXROTH adopt adopt joint venture
brand's gear pump, motor 		With protective glass and air
conditioning cab with
protective tipping gear.





Optional configuration



Model Motor                           other
LTS212H
LTS214H 		YC6108G 1.Puddlability random surveymeter
2.Removable convex block



Main Technical Parameters
MODEL Unit LTS214H LTS212H
Operating mass kg 14000 12000
Static linear load N/cm 342 300
Vibration amplitude mm 1.8/0.9 1.7/0.8
Vibration frequency Hz 29/35 28/35
Centrifugal force kN 290/160 260/160
Travel speed km/h 12 11
Grade ability % 30 30
Turning radius mm 6500 6500
Overall dimension mm 5860×2280×3020 5820x2278x3050
Vibration round width mm 2100 2100
Wheelbase mm 3160 3160
Ground clearance mm 472 472
Diesel power kw 110 110
Diesel model   6BT5.9 6BT5.9



 LTS 212H and LTS 214H single drum electric start hydraulic vibratory new road roller

LTS 212H and LTS 214H single drum electric start hydraulic vibratory new road roller



LTS 212H and LTS 214H single drum electric start hydraulic vibratory new road roller

LTS 212H and LTS 214H single drum electric start hydraulic vibratory new road roller







Main Features




1.   Motor:cummins6BTA5.9 extra-pressure diesel engine,have power man coffeciency,which comply with the      operating condition above 4000 meters altitude.

2.  Total hydraulic pressure,single drive,frequency and radiation conversion,articulated direction change, with stepless speed changes, advanced technology; Blocking the oil supply to brake the vehicle, safe and reliable.

3.  Streamiline outline, circular windshield glass and curvy hood form a unique style.
4.  Hydraulic pump and vibrating motors are of the 90 series made by the American manufacturer SAUER





Packaging & Shipping



Fixed it in the container with the steel wire rope and the fasten tie



Our Services

Engineers available to service machinery oversales
