Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Compactor > LTC212 Single Drum Electric Start Hydraulic Vibratory Road Roller
LTC212 Single Drum Electric Start Hydraulic Vibratory Road Roller
US$ 68,900 - 85,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Single Drum Roller
Static Linear Pressure:
286N/cm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Energy Saving Mining Ball Mill Machine With Competitive PriceUS$ 1,000 - 50,000MOQ: 1 Set -
Energy Saving Mining Ball Mill MachineUS$ 1,000 - 50,000MOQ: 1 Set
-
LTJ2125 Double Drum Hydraulic Static Grinding Road RollerUS$ 37,500 - 40,000MOQ: 1 Set
-
Heavy Hammer Crusher With Good CapacityUS$ 1,000 - 6,000MOQ: 1 Set
-
CYL31C Protable Vibratory Road RollerUS$ 3,200 - 3,500MOQ: 1 Set
Condition
New
Type
Single Drum Roller
Static Linear Pressure
286N/cm
Travel Speed
0-12.7 Km/H
Grade Ability
30%
Place of Origin
Henan, China
Brand Name
LUTONG
Model Number
LTC212
Power(W)
110 KW
Dimension(L*W*H)
5060*2250*3300 mm
Weight
12000 KG
Certification
QS,CE
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
LTC212 single drum electric start hydraulic vibratory road roller
Main Technical Parameters of LTC212 Road Roller
| MODEL | LTC212/LTC214 | MODEL | LTC212/LTC214 | ||
| Operating mass | kg | 12000/14000 | Travel speed | Km/h | 0-12.7 |
| Front axle load | kg | 6000/7000 | Turning radius | mm | 7000 |
| Rear axle load | kg | 6000/7000 | Grade ability | % | 30 |
| Static linear load | N/cm | 286/333 | Steering angle | ° | ±35 |
| Form of frame | Fork-type | Drum diameter | mm | 1350 | |
| Crabwise movement distance | mm | ±170 | Drum width | mm | 2100 |
| Water tank capacity | L | 2x600 | Drum rim thickness | mm | 20 |
| Fueltank capacity | L | 174 | Transverse swing angle of the vibrating wheel | ° | ±8 |
| Hydraulic tank capacity | L | 75 | Type of water apray | mm | pressure |
| Vibration frequency | mm | Wheelbase | mm | 3717 | |
| High ampl. | 0.8 | Overall length | mm | 5060 | |
| Low ampl. | 0.4 | Overall width | mm | 2250 | |
| Vibration frequency | Hz | Overall height | mm | 3300 | |
| High ampl. | 40 | Ground clearance | mm | 324 | |
| Low ampl. | 46 | Diesel model | 6BT5.9 | ||
| Centrifugal force | KN | Diesel power | kw | 110 | |
| High ampl. | 160x2 | Diesel speed | r/min | 2300 | |
| Low ampl. | 90x2 |
|
Standard configuration
| |
| 1.Full hydraulic two wheels drive and vibrating,CVT; | |
| 2.Engine:cummins6BT5.9 engine; | |
| 3.Travelling and vibrating system: adopte the products of SAUER or REXROT; | |
| 4.Hydrostatic center articulted steering,patented crab mechanism; | |
| 5.Rotating seats with the air conditioner in the cab; | |
| Optional configuration | |
| Driving system: Optional at the motor torque loaded poclain |
Main Features
1.Full hydraulic two wheel drive and vibration
2.Double frequency double vibration system
3.Hydrostatic center articulated steering,patented crab mechanism.
4.The driver's cabin can be turned on one side as a whole,to facilitate maintenance.
5.Cabin with air conditioner,comfortable and spacious,the flexible steering seat facilicates the operation.
6.Fork-type frame,good hold-down property.
7.Hydraulic pump and vibrating motors are of the products made by American manufacturer SAUER.
Packaging & Shipping
Fixed it in the container with the steel wire rope and the fasten tie
Our Services
Engineers available to service machinery oversales
