DC2001A Position Controller For Bag Making Machine

No.

Function explain

No.

Function explain

1,2

Main machine signal (JDQ1)

19

CCW step motor turn way

3,4

Power supply AC 220V

20

CP2 step motor pusle 2

5

-24V (GND)

21

CP1 Step motor pusle 1

6

+24V

22

KRUN  connect to “run” button externally

7,8

-12V (GND)

23

KSTOP connect to “stop”button externally

9,10

+12V

24

GK4 Jaming photoelectricity signal

11

BUZZ (low level output)

25

GK3  color photoelectricity signal

12

Clashing finestra signal-1 (JDQ6)

26

GK2  gk2 sensor

13

Clashing finestra signal-2 (JDQ5)

27

GK1 gk1 sensor

14

None

28

DONT inch the main machine

15

None

29

GK6 connect to “→” button externally

16

Pull signal (JDQ2)

30

GK7 Connect to “←”button externally

17

None

31

None

18

None

32

None
