SIMCO FMX-004 Electrostatic Fieldmeter

SIMCO FMX-004 Electrostatic Fieldmeter thumbnail-1
SIMCO FMX-004 Electrostatic Fieldmeter thumbnail-2
SIMCO FMX-004 Electrostatic Fieldmeter thumbnail-3
SIMCO FMX-004 Electrostatic Fieldmeter thumbnail-4
SIMCO FMX-004 Electrostatic Fieldmeter thumbnail-5
SIMCO FMX-004 Electrostatic Fieldmeter thumbnail-6
SIMCO FMX-004 Electrostatic Fieldmeter photo-1
SIMCO FMX-004 Electrostatic Fieldmeter photo-2
SIMCO FMX-004 Electrostatic Fieldmeter photo-3
SIMCO FMX-004 Electrostatic Fieldmeter photo-4
SIMCO FMX-004 Electrostatic Fieldmeter photo-5
SIMCO FMX-004 Electrostatic Fieldmeter photo-6
US$ 656 - 720 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
SIMCO
Model Number:
FMX004
Contact Supplier Request Quote Chat Now
Shantou Wingtai Packing Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shantou / Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Japan
Brand Name SIMCO
Model Number FMX004
Display Type Digital Only
Measuring Range +/-20 kV
Accuracy Class +/- 10%
Supply Voltage 9 V battery
Operating Temperature 10-40 deg C/RH:0.60%
Dimensions L115*W73*H25 mm
Weight 140 g

SIMCO FMX-004 Electrostatic Fieldmeter

Handy Digital Electrostatic Field Meter

Origin Place: Japan

Brand: SIMCO
Model No.: FMX004  Newest Version !
Measure Distance: 25±0.5mm
Accuracy: ±10%



Product Description



 Measure Range :

(1) AUTO MODE [Au] :  0 -±1.49kV (Lo Range) ;

                                        ±1.0kV - ±30.0kV (Hi Range)

(2) Low MODE [Lo] : 0 -±3.00kV

(3) Hi MODE [Hi] : 0 -±30.0kV

(4)Ion balance voltage measuring mode[Ib]: 0-±300V



Power Supply: 1 piece 9 v battery (006 p)
Biggest Action Time: about 30 hours
Shell Material: conductive ABS resin (gray)
Size: Body: 115 mm (L) x 73 mm (W) x 25 mm (H)
Ion balance board: 123 mm (L) x 73 mm (W) x 25 mm (H)



Feature



Features:

(1) Ion balance continuous measurement and data record.
(2) Testing result display and record show in a whole memory.
(3) Confirm record of the product anti-static status.
(4) FMX-004: continuous testing for 30 hours



Application



Using :

SIMCO FMX004 electrostatic fieldmeter can represent the static charge
through measuring aimed surface of static electricity based on non-contact way .
It is precise,easy take,easy use,very light and handy .



SIMCO FMX-004 Electrostatic FieldmeterSIMCO FMX-004 Electrostatic FieldmeterSIMCO FMX-004 Electrostatic Fieldmeter
