Shantou Wingtai static eliminator bar
- 5000 Unit / Units per Month
- Shantou / Shenzhen
- Credit Card
You May Like
Product Details
| Brand Name | Wingtai | Model Number | WT-A10 |
Product Description
Shantou Wingtai static eliminator bar
Pls contact online with the ion bar's length you need !
Working principle:
The anti-static ion bar can produce plenty of positive & negative ions, which can neutralize the products' ions that go through the ion radiation area. When the products surface with negative ion, it will attract radiation area’s positive ion; when the products surface with positive ion, it will attract radiation area’s negative ion, so that static on products surface will be neutralized, and then eliminate static electricity.
Features:
1. Use hard aluminum alloy material, beautiful appearance;
2. No electric shock design, more safe;
3. Built-in an unique high air volume tube;
4. Neutralize static electricity quickly
5. Stable and safe working performance
6. Easy and convenient installation
7. The ion bar has good ground protection
8. Ion bar should be equipped with a 7.0 KV generator
Suitable Industries:
It is suitable for anti-static in a flat occasion like thin material processing, slitting, coil stock, etc.
Technical data:
Input voltage | 220V~230V/50HZ (Special:110V~120V/60HZ If you need the special voltage, please contact online or leave messages.) | |
Output voltage | 7.0KV | |
Current consumption | 0.52mA/M | |
HV Cable Length | 3m | |
Working temperature | 0~50℃ | |
Anti-static time | ≤2S | |
Anti-static distance | Within 100mm | |
weight | 1.68Kg/M | |
Air pressure | 5-7Kg | |
Airflow rate | 10m/sec | |
Ion bar’s length | Customized | |
7KV High Voltage Generator:
Please Click the Headline to View More...
|
|
|
Ion Blower(One fan) | Ion Blower(Two fans) | Ion Blower(Three fans) |
|
|
|
Anti-static Ion Bar | Anti-static Brush | Antistatic Belt |
|
|
|
Anti-static Ion Air Gun | Anti-static Ion Nozzle | Simco Fildmeter FMX-004 |
