2016 most popular low price wood crusher machine / straw crusher machine
The introduction of wood crusher
Wood crusher is the special chipping/crushing equipment for raw wood with 50-250 mm (diameter). During the working process, the raw wood will be chipped, re-crushed and sieved.The wood crusher combines chipping with crushing in one machine to get the wood sawdust directly. The final diameter of wood can reach to 2-5 mm, which is suitable for further drying and briquetting.
The raw material of wood crusher
crash sawdust,rice hull, bamboo powder, peanut husks, furfural dregs, husks of sunflower seed,wine stillage, bagasse,corn cobs,cocoanut shells, coffee ground .
Technical Parameters
Model |
Power |
Capacity |
Cutter diameter |
Cutter No. |
Weight |
Size |
40 |
7.5kw |
48kg |
0.4 |
4 |
350kg |
1.25*0.65 * 0.75 |
60 |
18.5kw |
1300kg |
0.6 |
6 |
1100kg |
1.8*1.3*0.9 |
80 |
22kw |
2000kg |
0.7 |
6 |
0.5T |
2.1*1.5*1.3 |
1.For some large wood logs and square logs, chipping is necessary before crushing.Wood crusher integrates the chipping and crushing process thus saving much labor and
energy.
2.To ensure safe processing, the machine adopts self feeding method and avoids any possible damage when metal piece is mistakenly put into the chamber.
Structure of wood crusher
It is composed of machine body, knife chipping part, chips re-crushing part andsieving part,etc.It combines both chipping and crush in one machine, can make sawdust in one passage, no need to use wood chipper for preprocessing of wood logs.
Working principle of wood crusher
1,At the edge of cutter, there are several blades, when the wood crusher is working, the rotator will do fast rotarion and drive cutter do rotation.
2.When the raw material get into the inner of wood crusher, the balde will continuously cut the raw material and the harmmers is repeatly beat the material until the final material can pass the screen.
3.The rotator also drive the wind wheels, and the wind wheel can produce the strong wind to blow the final material all the time.
4.The final material come ourt from the discharge port of wood crusher under the influence of storng wind and gravity.
Feature of wood crusher
1). High-efficient and energy-saving: 40% power consumption reduced at equivalent output;
2). Extra long life: hammer heads are made of new type of high quality alloy materials with multiple elements and can be turned for use thus to prolong the service life by 4 times.
3). Great crushing ratio: incorporating primary & secondary crushing for clinkers and secondary & teritary crushing for limestone into one step.
4). Easy Maintenance: The rear cover of the upper machine frame can be hand-opened to make the maintenance much easier.
Packing details
50% pre-payment,we will commence production of the machines upon recieving the first payment. The outstanding balance should be paid in full before the goods can be shipped.
Delivery
within 15 days.
Service
1. Before Sale: help you to set a purchase plan according to your requirment
2. During Sale: accompany you to check the performance of the machine
3. After Sale: Sent engineer to your place and help you with the installation
