Home > Industrial Equipment & Components > Power & Generating Sets > Gas Generator > Biogas, Natural Gas Generator 200KW With Camda Designed Engine

Biogas, Natural Gas Generator 200KW With Camda Designed Engine

Name: Biogas, Natural Gas Generator 200KW With Camda Designed Engine
Brand: Camda
SKU: 138277411

Biogas, Natural Gas Generator 200KW With Camda Designed Engine thumbnail-1

Biogas, Natural Gas Generator 200KW With Camda Designed Engine thumbnail-2

Biogas, Natural Gas Generator 200KW With Camda Designed Engine thumbnail-3

Biogas, Natural Gas Generator 200KW With Camda Designed Engine thumbnail-4

Biogas, Natural Gas Generator 200KW With Camda Designed Engine photo-1

Biogas, Natural Gas Generator 200KW With Camda Designed Engine photo-2

Biogas, Natural Gas Generator 200KW With Camda Designed Engine photo-3

Biogas, Natural Gas Generator 200KW With Camda Designed Engine photo-4

US$ 15,000 - 40,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Camda

Model Number:

KDGH200-G

Contact Supplier Request Quote Chat Now

Camda New Energy Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Camda

Model Number KDGH200-G

Output Type AC Three Phase

Speed 1500/1800rpm

Frequency 50/60Hz

Rated Power 200KW/250KVA

Rated Voltage 280/380/480V

Rated Current 380A

200KW/250KVA Biogas gerator 200kw/Gas generator/Gas engine/Gas generaotor set/biogas genset/Power plant/Natural gas generator with ISO&CE certificates

Product Description

Model: KDGH200-G

Frequency: 50HZ

Speed: 1500RPM

Voltage: 380V/220V, 400V/230V, 415V/240V

Fuel: Natural Gas and Biogas

Genset Specification

Gas genset data
Genset model	KDGH200-G
Maximal power (kW/KVA)	200/250
Prime power(kW/KVA)	180/225
Continuous Power(kW/KVA)	160/200
Connection Type	3 Phases 4 Lines
Power factor cosfi	0.8 lagging
Frequency (Hz)	50
Rated speed (RPM)	1500
Open type Genset Overall Dimension (mm)	3150x1100x1800
Soundproof type Genset Dimension (mm)	4600x1600x2200
Net weight without canopy(kg)	2525
Gas Engine Data
Model		HGNT14
Brand		CAMDA
Type		4 stroke, water-cooling, wet cylinder liner, electronic-control ignition system, pre-mixed perfect mixed burning
Cylinders& Arrangement		6L
BoreXStroke(mm)		140X152
Displacement(L)		14
Compression ratio		11:1
Aspiration		Intercooled and Turbocharged
Cooling Method		Radiator fan water cooling
Governor type(speed regulating type)		Electronic governing
Starting method		Electric, 24 V motor
The lowest gas consumption(m3/kw.h)		0.3 for natural gas/0.6 for biogas
Idling speed(r/min)		700
Oil recommended		SAE 15W-40 CF4 or above
Oil consumption		≤1.0g/kW.h
Alternator Data
Brand			France Leroy Somer
Model			LSA46.2L6/200KW
Rated power			200kW / 3 phase
Rated Voltage (V):			380~480 (±0.5%)(AC)
Type			3 phase/4 wire, brushless, automatic voltage regulator, drip proof, protected type.
Frequency (Hz)			50
Efficiency:			93.6%
Voltage regulation			± 0.5 %(adjustable)
Insulation class:			Class H
Protection class:			IP 23
cooling method:			wind-cooling, self-heat-rejection
Voltage regulating mode			Automatic voltage regulator
Compliant with international standards:			IEC 60034-1, NEMA MG1.22, ISO 8528/3, CSA, UL 1446, UL 1004B on request, marine regulations, etc.

Features of Camda H series gas genset

Specially-designed air valves, crankshaft, camshaft, pistons, ignition system and combustion chamber according to gas combustion characteristics.

Long life span. Camda gas engine is designed and developed through the cooperation between joint venture and CAMDA. The gas engine life span reaches 30 years.

Long designed overhaul term: 25,000 ~ 30,000 hours.

Total cogeneration efficiency is around 83%, higher than other China brands by 5%.

Four air valves designing for each cylinder. Sufficient air intaking and exhausting to realize maximum power output.

Easy access to spare parts. it's very convenient to find any parts at anytime and anywhere.

Electronic Air/Gas mixer. The mixer guarantees optimum air-fuel ratio, improves thermal efficiency, reduces NOx emission. Unique air-fuel ratio adjusting system suits 30% ~ 90% methane density.

Ignition system. Altronic ignition system imported from USA ensures high-precision ignition, which enhances genset life span and stability.

Equipped with world-famous Leroy Somer alternator, providing stable and durable output.

Full automatic and intelligent control system IG-NT from Czekh enables easy operation and automatical inspection for genset running status.

Production Complying to CE standards, ISO9001:2008 Quality Management System, ISO14001:2004 AND ohsas18001:2007.

Free of charge training for operation and maintenance. (at Camda headquarter)

Packaging & Shipping
