ABS PVC AS auto flow meter Plastic material water meters

FOB Price

USD $5 - $190 / Piece

1 Piece(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port SHANGHAI
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	Duoling, Duoling
Model Number	LZB-S

Product Description

Modcl

Flowrate

(water 20°C)

Condition

Socket

FBSP

thread

LZB-15S

2-20L/h

3-30 L/h

4-40 L/h

5-50 L/h

6-60 L/h

10-100 L/h

16-160 L/h

25-250 L/h

40-400 L/h

50-500 L/h

60-600 L/h

100-1000 L/h

280

Φ20

G½“

Accuracy:

±4%

Pressure:

≤1MPa

Temp.:

0℃-60℃

LZB-25S

100-1000L/h

160-1600 L/h

250-2500 L/h

300-3000 L/h

380

Φ32

G ¾“

LZB-40S

(with guiderod)

0.4-4m³/h

0.6-6 m³/h

1-10 m³/h

420

Φ50

None

LZB-50S

0.4-4 m³/h

0.6-6 m³/h

1-10 m³/h

435

Φ63

G1½“

1.6-16 m³/h

(with guiderod)

Tips:

1. There are three connection types: BSP thread type, socker-end type,and flange type.(This structure sketch takes socket-end connection type as example.)

2. Flowmeter is used for measuring the flow rate of liquid or air.

Model

Flowrate (Water 20oC)

Condition

Socket

FBSP

Thread

LZB-15S

(with guiderod)

5-50L/h 6-60L/h 10-100L/h 16-160L/h 25-250L/h 40-400L/h 60-600L/h 100-1000L/h

200

Φ20

G½“

Accuracy: ±4%

Pressure: ≤1MPa

Temp.: 0oC-60oC

LZB-25S

(with guiderod)

100-1000L/h 160-1600L/h 250-2500L/h 300-3000L/h

230

Φ32

G¾“

LZB-32S (with guiderod)

400-4000L/h 600-6000L/h

288

Φ40

G1”

LZB-50S (with guiderod)

0.4-4m³/h 0.6-6 m³/h 1-10 m³/h 1.6-16 m³/h

341

Φ63

G1½”

LZB-65S (with guiderod)

3-16m³/h 5-25m³/h 8-40m³/h 10-50m³/h 12-60m³/h

430

Φ75

G2”

LZB-80S (with guiderod)

3-16m³/h 5-25m³/h 8-40m³/h 10-50m³/h 12-60m³/h

533

DN80 flange

None

LZB-100S (with guiderod)

8-50m³/h 10-60m³/h 14-90m³/h 18-120m³/h 18-150m³/h 20-180m³/h 20-200m³/h 20-220m³/h

555

DN100 flange

None

LZB-125S (with guiderod)

DN125 flange

LZB-150S (with guiderod)

DN150 flange

(1)Before installation, take out foam
supports in the tube carefully. Make sure the rubber ring is installed correctly on the indentation.
(2)This Flowmeter can be equipped with ABS pipe or PVC pipe by using special glue to connect. It also has flange or thread connection.
(3)This flowmeter should be installed
vertically and be convenient to read the scale. When reading, keep the sight and the float horizontal.(General
standard: the best flow to be measured
should be 50%~70% of max flowrate.
Try not use the maximum value.)
(4)The straight lengths of both inlet and outlet pipes connected with the flowmeter should be more than five times of the flowmeter’s length.
(5)The pressure of liquid should be stable. If the pressure of liquid is not
stable, it will lead the wave of floater and cannot measure correctly, then a buffer or setting adjuster should be set above the flowmeter.
