Specifications
1.High dry capacity,smooth rotation2.Low energy consumption
3.Easy operation, high output
Features of The Chicken Manure Dryer:
1. High mechanized, high capacity, continuous working.
2. Simple structure, steady move of manure, easy operation.
3. Few malfunction, low maitenance cost, low energy consumption.
4. Wie application, equal drying degree.
5. Enbironmentally friendly, high waste recycling rate.
6. Make use of natural fertilizer, make profit and make farm product greener.
Working priciple of The Chicken Manure Dryer:
Materials are sent to hopper of Rotary Dryer by belt conveyor or bucket elevator. The barrel is installed with slope to horizontal line. Materials enter the barrel from the higher side, and hot air enters the barrel from the lower side, materials and hot air mix together. Materials go to the lower side by gravity when the barrel rotates. Lifters on the inner side of barrel lift materials up and down to make materials and hot air mix completely. So drying efficiency is improved.
Technical Parameter of The Chicken Manure Dryer:
| Model | Shell diameter(mm) | Shell length (mm) | Slope(º) | Rotary speed(r/min) | Weight(t) | Power(kw) | Volume(m3) |
| ø0.6x8 | ø600 | 8000 | 3-5 | 8 | 5.1 | 6-4 | 2.26 |
| ø0.8x10 | ø800 | 10000 | 3-5 | 7.2 | 6.9 | 6-4 | 5.02 |
| ø1x10 | ø1000 | 10000 | 3-5 | 6.73 | 7.5 | 6-5.5 | 7.85 |
| ø1.2x12 | ø1200 | 12000 | 3-5 | 5.8 | 13.1 | 6-11 | 13.31 |
| ø1.5x12 | ø1500 | 12000 | 3-5 | 4.8 | 22.3 | 6-15 | 21.2 |
| ø2.2x14 | ø2200 | 14000 | 3-5 | 3.2 | 52.8 | 30 | 53.22 |
| ø2.4x18 | ø2400 | 18000 | 3-5 | 3 | 73.3 | 37 | 81.43 |
| ø2.8x24 | ø2800 | 24000 | 3-5 | 2.59 | 97 | 75 | 147.8 |
The Detail Pictures
The Structure of The Chicken Manure Dryer:
Draught fan transmission device Pipes
discharge head discharge cover Spiral conveyor
The Packing Pictures of The Manure Dryer:
