ISO9001:2008 advanced technology rotary sawdust dryer machine with competitive price

Specifications

Rotary drum dryer:
1)ISO9001 approved
2)Low energy consumption
3)Inventory:Yes

Features of The Rotary dryer:

  1. Great drying intensity.

  2. Short drying time

  3. The air current water extractor is with simple structure, being easy to construct and service.

  4. High capacity, high thermal efficiency.



Working priciple of The Rotary dryer :

        Materials are sent to hopper of Rotary Dryer by belt conveyor or bucket elevator. The barrel is installed with slope to horizontal line. Materials enter the barrel from the higher side, and hot air enters the barrel from the lower side, materials and hot air mix together. Materials go to the lower side by gravity when the barrel rotates. Lifters on the inner side of barrel lift materials up and down to make materials and hot air mix completely. So drying efficiency is improved.



Technical Parameter of The Rotary dryer :



Model	Shell diameter(mm)	Shell length (mm)	Slope(º)	Rotary speed(r/min)	Weight(t)	Power(kw)	Volume(m3)
ø0.6x8	ø600	8000	3-5	8	5.1	6-4	2.26
ø0.8x10	ø800	10000	3-5	7.2	6.9	6-4	5.02
ø1x10	ø1000	10000	3-5	6.73	7.5	6-5.5	7.85
ø1.2x12	ø1200	12000	3-5	5.8	13.1	6-11	13.31
ø1.5x12	ø1500	12000	3-5	4.8	22.3	6-15	21.2
ø2.2x14	ø2200	14000	3-5	3.2	52.8	30	53.22
ø2.4x18	ø2400	18000	3-5	3	73.3	37	81.43
ø2.8x24	ø2800	24000	3-5	2.59	97	75	147.8



The Structure of The Rotary dryer :





                 Draught fan                              transmission device                                  Pipes







               discharge head                                 discharge cover                              Spiral conveyor









The Packing Pictures of The Rotary dryer :
