automatic folder gluer
Mainly introduction automatic folder gluer
1. Feeding: Automatic and continuous feeding
2. Adhesive: Solute type
3. Basic box gluing methods: one side-gluing, both sides side-gluing, bottom gluing
Max speed |
220m/min |
Suitable paper |
250-700g/m³ |
Past form |
One-side edge pastes,two-side paste, bottom pastes |
Feeding way |
Automatic feeding |
Machine weight |
3000kg |
Power |
6kw, |
Machine size |
8.4x1.3x1.45m |
Main parts of automatic folder gluer
The Machine consists of feeding, paper correction, pre-folding, bottom locking, folding, full pressing, press and so on.
Feeding section:
1. 5 independent feeding belts ensure the stability of paper feeding and easy calibration.
2. Continuously Variable Speeder to ensure the blank in even distance, and stable transmission
3. Pneumatic cutting lifting makes it easy to adjust the feeding belt.
Pre-folding section:
1. Double-board structure (with a set of pre-folding knife)
Bottom-gluing section
1. 3-board structure
2. Equipped with glue-applying device
Folding section :
1. Double-board structure
Full pressing:
1.2-board structure
2.Two modes for pressing belt speeding:
Auto: set distance between boxes, pressing belt speed is the same as the machine, belt removes while opto-electronic detect it.
Manual: pressing belt conveys in a fixed speed and machine speed will not put any effect on it.
3. With counting device to count the finished boxes to match with boxes regulating, easy to count and pack
Back machine
1. Equipped with feeding paper inspection device.
2. Equipped with impacting device to press the paper after accounting and make it easy to pack paper.
Working principle of automatic folder gluer
Warranty: 1 year
