Specifications
CE Manufacture used wood briquettes press machine1.Long-serve time
2.Excellent performance
3.Good quality
CE Manufacture used wood briquettes press machine
Introduction
1, Raw material of wood briquette machine:
sawdust, wood chips, branches, crop stalks, sugarcane residue, coffee husk, paddy straw, sunflower stalk, cotton stalks, bamboo dust, palm husk, soybeans husk, tea waste, etc
2, Features of used wood briquettes press machine :
Making briquette is fast(the briquette is 60cm/20s), Large extrusion density, propeller with special wear-resistant materials, precision casting, life was over ten times more rapid than conventional.
Forming the sleeve with a specially formulated alloy casting, life span of a year. This sophisticated technique not only lowers the cost greatly but also saves manpower.
3, Application of used wood briquettes press machine
As the need of pollution free environment, the product has a large scope of marketing. The briquettes can be used as a substitute of any fuel in following fields:
a, Boilers: It can be used in the boilers of Paper Mills, Sugar Mills, Dyeing houses, leather, lamination industries, Vanaspati units,
b, Food Processing Units, Oil Extraction Units, Solvent Extraction Plant and many other plants and industries.
c, Furnace&Foundries: It can be used for metal heating & melting (where melting point is less than 1000d/cel.)
d, Brick Kilns: It is the total, substitute of steam coal.
e, Residential&Commercial Heating: For winter heating in Cold areas and Hotels, Canteens, Cafeterias and house hold kitchen appliances etc.
4, Production line
Technical Parameter
Model |
LTB-50 |
LTB-80 |
Productivity |
150-210kg/h |
350-400kg/h |
Motor power |
11kw |
22kw |
Electric heater motor power |
6kw(gear box) |
9kw(gear box) |
Size of raw material |
Length<5mm,Dia.<3mm |
Length<5mm,Dia.<3mm |
Moisture content of raw material |
8%-12% |
8%-12% |
Burning calorie |
4500-5500Kcal |
4500-5500Kcal |
Briquette Density |
1.4g/CBCM |
1.4g/CBCM |
Burning time |
134-167hours/t |
134-167hours/t |
Raw material:Briquette(volume ratio) |
30:1 |
30:1 |
Raw material:Briquette(weight ratio) |
1:15 |
1:15 |
Briquette diameter |
50mm |
60-80mm |
Diameter of center hole |
15-20mm |
15-20mm |
Machine Weight |
610kg |
1300kg |
Outside size |
1710*750*1280mm |
1960*880*1620mm |
