Specifications
1. High profit and low cost in raw material2. Increase the net calorific value per unit volume after briquette
3. Energy save
Hot Sales Coal Dust/Powder Briquette Press Machine
Coal briquette machine:
This machine is widely used to recycling the mineral wastes, and processes them into briquettes for re-use. Due to the large quantity of materials resources, based on different materials density, we have developed several types of briquette machine, mechanical pressure briquette machine, hydraulic pressure briquette machine and strong pressure briquette machine with screw feeder.
The applicable material is very wide, such as iron powder, coal powder, charcoal powder, coke powder, many kinds of ferrous and non-ferrous metal ores, fireclay material, and other industrial tailing wastes. All of these materials could be compress into briquettes.
Please tell me that your raw materials, I can give you some suggestions on the pressure of briquette machine.
| Model: HSYQ-290 |
| Power: 5.5-7.5 kw (three phases, 380V, 50HZ) |
| Discharging belt conveyor power: 2.2kw |
| Diameter of roller:290mm |
| Width of the roller: 200mm |
| The largest pressure: 5-6T |
| Coal capacity: 1-2t/h |
| Coke capacity: 1-2t/h |
| Charcoal Capacity: 0.6-0.8t/h |
| Final briquette diameter: 30-50mm |
| Material of roller:65Mn |
| Lifetime of the roller: about 1 year |
| Diameter of the gearbox: 350mm |
| Applicable materials: cola, charcoal, metal powder, etc. |
| Shape of final products: ball, pillow,bread,etc. |
| Mode of Operation:Four Rollers Squeezing |
| Weight: 700 kg |
| Pack size:1.8*1.2*1.6 m |
Final briquettes:
